Clamp Identification
Use Oetiker clamps for making hose connections.
These clamps provide co rrosion resistance, mini-
mize the potential for abrasion of rigging compo-
nents, and provide solid, permanent connections.
The selection and installation of an Oetiker clamp
is essential in the p roper sealing of h ose connec-
tions. The clamp identification numbers appear on
the side of the cla mp, near the top of the
Refer to Clamp Selection chart for dimensions.
A
WARNING
DO NOT re-use Oetiker clamps. Fuel leak-
age could contribute to a fire or explosion.
Clamp Selection
To select the c orrect size Oetiker clamp, measure
the outside diameter of the hose when installed on
the fitting.
