ROUTINE SERVICE
OUTBOARD RIGGING CONNECTIONS
3 C
M
YLINDER
ODELS
EMM CANbus connector cap is clipp ed to EMM
cooling water h ose. Remove clip from cap
install on I-Command harness connector.
1
1. Canbus harness connector
2. EMM CANbus connector cap and clip
Install clip and connector to hose.
1
1. CANbus connectors
2. EMM cooling water hose
22
A
M
LL
ODELS
Adjust harness routing as needed and secure with
and
tie straps.
Use an I-Command Ignition and Trim Harness to
connect the outboard to the key switch and trim/tilt
control. Sea l unused SystemCheck co nnector
2
with 6-Pin Connector Seal, P/N 586076.
If conne cting to an existing I-Command Classic
network, connect the purple wires bet ween the I-
Command Ig nition and Trim Harn ess an d the I-
Command Engine Interface Cable. T his connec-
tion supplies power to th e network when th e key
switch is on. I-Command Digital networks do not
use this connection.
006743
1
2
2
3
1. Trim/Tilt connector
2. CANbus Ignition connector
3. SystemCheck connector (with seal)
4. Deutsch-style harness power connector
006744
4
006734
