ROUTINE SERVICE
OUTBOARD RIGGING CONNECTIONS
Move control handle to FOR-
IMPORTANT:
WARD and pull back slowly t o NEUT RAL. Make
sure the engine throttle lever is against the stop. If
not, remove slack by adjusting cable trunnion.
After grommet ha s been installed in lower engine
cover, install the washers and retainer clips on the
throttle and shif t leve r pins.
Retainer Clip Installation on p. 18.
Install cable retainer and screw. Tighten screw to
a torque of 60 to 84 in. lbs. (7 to 9.5 N·m).
SystemCheck Harness
Connections
Place th e wirin g harne ss through notch in lower
motor cover a nd ro ute t o the recess in th e fly-
wheel cover. Secure the cable with a tie strap as
shown:
1
1. Recess
2. Tie strap
Before installing electrical connectors, check t hat
the seal is in place. Cl ean off any dirt from con-
nectors. Apply a light coat of Electrical Grease to
20
the seal only. DO NOT fill connectors with Electri-
cal Grease.
Refer to Cable
1. Seal
Arrange connectors in flywheel cover.
002103
Install electrical cover and secure with screws.
2
NOTICE
are not pinched, cannot contact flywheel, and
002011
do not interfere with moving throttle or shift
linkages.
BE SURE all harnesses and wires
1
42079A
001999
002102
