Evinrude E-Tec 40 HP Service Manual page 120

ELECTRICAL AND IGNITION
CONNECTOR SERVICING
S S
UPER EAL
The J1-A and J1-B conn ectors of the EMM are
AMP Super Seal connectors.
Disconnect
Depress BOT H latches and pull con nector from
plug.
Connect
Push connector into plug until latches engage.
1
1
1. Latch
Terminal Removal
Open lock me chanism and remove terminal from
connector housing.
2
1
1. Latch
2. Lock mechanism
Terminal Installation
Push terminal through seal until it is seated in con-
nector housing. Close lock mechanism.
1
1. Terminal
118
P T
OWER IMER
The J2 conne ctor of the EMM is an AMP Power
Timer Series connector.
Disconnect
Use a screw driver to open latch. Pull co nnector
from plug.
Connect
Push connector until seate d in plug. Close latch
completely.
1
2
002118
1. J2 connector
2. Latch (closed)
Terminal Removal
Use Terminal Rele ase T ool, P/N 351413, to
release BOTH locking mechanisms of con nector.
2
Pull terminal from housing.
1
002453
1. Locking mechanism(s)
1. Terminal release tool
002454
S
ERIES
002120
1
1
002455
002313
