ELECTRICAL AND IGNITION

IGNITION COIL SERVICING

Thoroughly clean t he crankshaf t and f lywheel
tapers with Cleaning Solvent and let dry.
Align the f lywheel keywa y a nd inst all flywhee l.
Coat the threads of flywheel nut with Triple-Guard
grease. Install the washer and nut and tighten to a
torque of 100 to 115 ft. lbs. (136 to 156 N·m).
Replace flywheel co ver and recoil st arter (rope
start models).
Check ignition
IMPORTANT:
wheel removal or replacement. Refer to
ADJUSTMENTS on p. 113.
112
IGNITION COIL
SERVICING

Ignition Coil Removal

Remove spark plug lead from ignition coil and dis-
connect ignition coil electrical connector.
Remove two ignition coil retaining screws.
Do not lose the rub ber washers between coil and
bracket.
002093
1. Screws

Ignition Coil Installation

Install one rubber wa sher on each screw
install screw through ignition coil.
Install remaining rubbe
between coil and bracket.
002090
timing af ter fly-
TIMING
1. Rubber washers
Install coil on bracket. Tighten screws to a torq ue
of 60 to 84 in. lb. (7 to 9.5 N·m).
Install spark plug lead on ignition coil and connect
ignition coil electrical connector.
1
1
008187
and
r washers on scre ws
008188
1
