ELECTRICAL AND IGNITION
ELECTRIC START TESTS
Key Switch, START Position
Key switch START:
Switches 12 V to terminal "S" of key switch and
•
to the neutral safety switch (in remote control).
A closed neu tral safety swit ch provides 12 V to
•
the en gine wire ha rness yellow/red wire an d
solenoid (terminal "A").
M
A
4
5
6
3
2
1
1. Ignition switch, START position – Continuity
between terminals "B" and "A"; "B" and "S"
2. Terminal "S", 12 V
3. Neutral safety switch
102
1
B
M
C
S
B
C
M
A
2
3
000691R
ELECTRIC START TESTS
Starter Solenoid Test
Disconnect the B+ (POS) battery cable at the bat-
tery.
IMPORTANT:
noid terminals before proceeding with this test.
Use a digital multimeter to measure resistance.
Put on e me ter lea d on th e st arter p ositive (+)
cable terminal an d th e ot her lead on the battery
positive (+) cable terminal:
Meter must not show continuity (high reading).
•
If meter shows continuity (low reading), replace
•
the solenoid.
M
S
1
1. Battery positive cable (B+) terminal
2. Starter positive (+) cable terminal
3. "A" terminal (yellow/red)
4. "B" terminal (yellow/green)
Apply B+ to te rminal "A" of solenoid and grou nd
(NEG) to terminal "B" of solenoid. Measure re sis-
tance between the starter positive (+) cable termi-
nal and the positive battery (+) cable terminal.
The solenoid must close with an audible click.
•
Meter must show continuity (low reading).
•
If met er shows no con tinuity (high reading),
•
replace the solenoid.
After re-installing the solenoid, coa t all wires a nd
terminals with Black Neoprene Dip.
Disconnect all wiring
2
POS
+
A
B
3
4
from sole-
002073
