ELECTRICAL AND IGNITION

ELECTRIC START CIRCUIT

ELECTRIC START CIRCUIT
Start Circuit Diagram
12
1. Marine battery
2. RED wire (POS)
3. BLACK wire (NEG)
4. Starter solenoid
5. Fuse (10 amp)
6. RED/PURPLE wire
7. Key switch connectors
8. Ignition switch
100
1
2
3
4
5
6
9
B
M
M C S
8
A
A
15
NEG
–
3 2
+
1
7
13
11
1 2
4 5
FUSE
1 2
A B
9
B
26
6
27
28
29
30
31
32
33
34
14
9. PURPLE wire (switched B+)
10. Engine Management Module (EMM)
11. YELLOW/RED wire, start
12. Neutral Safety Switch (remote control)
13. Neutral Safety Switch (engine)
14. RED starter motor cable
15. Electric starter motor
1
18 18 10 10
2
19 11 11
3
20 12 12
4
J1-A
13 13
21
5
14 14
22
6
15
23 15
7
16
24 16
8
17 17
25
9
J1-B
9
1
10
2
11
3
12
J2
4
13
5
14
6
15
7
16
8
10
008049
