- Page 1 Assembly and operating instructions REMKO SLE series Pool dehumidifiers SLE 20 Read the instructions prior to performing any task! Edition GB - N11...
-
Page 3: Table Of Contents
Contents Air dehumidification Safety notes Unit description Set-up Commissioning Shutdown Care and maintenance Troubleshooting Electrical wiring diagrams Diagram, cooling cycle Exploded view of the condensate tank Spare parts list for the condensate tank Exploded view of the SLE 20 Spare parts list for the SLE 20 Maintenance protocol Intended use Customer service and guarantee... -
Page 4: Air Dehumidification
REMKO SLE series Air dehumidification The correlations occurring when With regard to energy air is dehumidified are based consumption, air dehumidification on physical laws. has one distinct advantage: These are depicted here in graphical form in order Energy expenditure is limited... - Page 5 REMKO air dehumidifier. of water vapour contained remains such as brick 90-190 l/m³, heavy The air is dehumidified and, constant and so relative humidity concrete 140-190 l/m³...
-
Page 6: Safety Notes
REMKO SLE series Condensation heat The Energy transferred to the air Conversely, energy is released When dehumidifying, a heat from the condenser consists of: when gas is liquefied, this is cycle is created, whereby heat designated as condensation heat. is consumed for evaporation 1. -
Page 7: Unit Description
Unit description The units have been designed Operating sequence Continuous circulation of for universal and straightforward the room air through the unit air dehumidification. The operating switch and gradually reduces the relative Their compact dimensions allow the integrated hygrostat are humidity (% RH) in the room to them to be installed in many used to switch the units on and... -
Page 8: Set-Up
REMKO SLE series Set-up For optimum and safe use Electrical wiring Condensate water drain of the units, the following notes must be followed in full: The units are The condensate water drain ■ operated with is located on the unit's base. -
Page 9: Commissioning
Commissioning Additional condensate tank Installing the condensate tank Before commissioning the unit or if local requirements dictate, the air- In situations where natural Attach the unit to the wall inlet grill and air-outlet grill must ■ condensate drainage is not possible bracket provided be checked for contamination. -
Page 10: Shutdown
REMKO SLE series Care and maintenance Operation display LED Cleaning the suction filter NOTE Regular care and maintenance LED on the front panel illuminates: Check the suction filter at regular is fundamental to a long Green = Unit dehumidifying intervals and clean if necessary. -
Page 11: Troubleshooting
Troubleshooting The units are manufactured The unit switches off The red indicator light using state-of-the-art production automatically, does not restart (malfunction) also illuminates for 45 minutes and switches if the condensate tank methods and tested several times to verify their correct function. off again after a short time is empty However, if a functional fault... -
Page 12: Electrical Wiring Diagrams
REMKO SLE series Electrical wiring diagram Electronic control board Legend: HYG = Hygrostat (internal) M1 = Compressor M2 = Fan = Operating switch TS1 = Condenser probe TS2 = Evaporator probe = Solenoid valve Cooling cycle Legend: 1. Compressor 2. Evaporator 3. -
Page 13: Exploded View Of The Condensate Tank
Condensate tank (accessory) Additional condensate tank In situations where natural condensate drainage is not possible or is very difficult, the unit can be equipped with an additional condensate tank. The condensate tank is installed directly below the unit. If the unit is used with a condensate tank, the dehumidifier switches off automatically when the tank is full. -
Page 14: Exploded View Of The Sle 20
REMKO SLE series Exploded view of the SLE 20 We reserve the right to modify the dimensions and design as part of the ongoing technical development process. - Page 15 Spare parts list Designation Wall-mounted bracket 1109100 Complete housing 1109101 Compressor, cpl. 1109102 Complete start relay 1109103 Operating switch 1109113 Fan motor 1109105 Fan blade 1109106 Control board 1109107 LED board 1109108 Electronics cover 1109109 Solenoid valve, cpl. 1109110 NTC condenser probe 1109112 NTC evaporator probe (metal) 1109111...
-
Page 16: Maintenance Protocol
REMKO SLE series ✍ Maintenance protocol Unit type: ........Unit number: ........10 11 12 13 14 15 16 17 18 19 20 Unit cleaned - outside - Unit cleaned - inside - Condenser cleaned Evaporator cleaned Fan function checked... -
Page 17: Intended Use
When disposing of packaging and return the ”Certificate of material, please consider our A failure to observe the guarantee” to REMKO GmbH & environment. manufacturer's specifications, the Co. KG at the time when the units Our units are carefully packed respective local legal requirements are purchased and commissioned. -
Page 18: Unit Dimensions
REMKO SLE series Unit dimensions SLE 20 standard SLE 20 with condensate tank All measurements in mm We reserve the right to modify the dimensions and design as part of the ongoing technical development process. -
Page 19: Technical Data
Technical data Series SLE 20 Daily dehumidification capacity at 30 °C and 80 % RH Litres/day 10.5 Daily dehumidification capacity at 30 °C and 60% RH Litres/day Operational temperature range °C 3-30 Usable humidity range % RH 40-100 Air volume Refrigerant R134a Refrigerant quantity... -
Page 20: Exploded View Of The Sle
