Meter Selection Factors - Total Control Systems 700-20 Engineering Manual

METER OPERATING SPECIFICATIONS
Type
Meter
Available
SP, SPA,
700-15
IP & IC
SP, SPA,
700-20 SPD, IP, IC,
AF & SS
700-20 LP
700-25 SPA, SPD
SP, SPA,
700-30 SPD, IP, IC
& AF
700-35 SPA, SPD
SP, SPA,
700-40 SPD, IP, IC
& AF
700-45 SPA, SPD
* Flanged NPT is Standard; BSPT, Slip Weld, ANSI and others are available upon request.
** Higher working temperatures can be achieved at reduced pressures (consult factory for more information)

METER SELECTION FACTORS

WEIGHTS&MEASURES
Before any meter can be specified, knowledge of each application is required. If the liquid is to
be sold through a metered delivery, domestic or international certification from a governing body
may be required. Total Control Systems strictly adheres to all domestic and international
metrology conformance regulations for the custody transfer of fluids. For questions regarding
weights and measures approvals or other issues, please consult factory.
Flange Maximum
*
Connection
1½"NPT Flange;
2" optional
(227 LPM)
2" NPT Flange;
100 GPM
1½"optional
(380 LPM)
2" NPT Flange;
100 GPM
1½"optional
(380 LPM)
150 GPM
2" NPT Flange
(567 LPM)
3" NPT Flange
200 GPM
2"optional
(760 LPM)
300 GPM
3" NPT Flange
(1135 LPM)
4" NPT Flange;
500 GPM
3" optional
(1893 LPM)
600 GPM
4" NPT Flange
(2271 LPM)
