Multi-Spectrum Digital
Electro-Optical Fire Detectors
MODEL SS3
(Models SS3-A, SS3-AN, SS3-AB, and SS3-ABN)
STAND-ALONE MODE or FS2000 SYSTEM MODE
Installation Guide
and
Operating Manual
____________________________________________________________________________________________________________________
Fire Sentry Corporation
Document No. 1508-002 - Rev B
© Copyright 2009
All Rights Reserved
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Fire Sentry SS3
Summary of Contents for Fire Sentry SS3
- Page 1 Multi-Spectrum Digital Electro-Optical Fire Detectors MODEL SS3 (Models SS3-A, SS3-AN, SS3-AB, and SS3-ABN) STAND-ALONE MODE or FS2000 SYSTEM MODE Installation Guide Operating Manual ____________________________________________________________________________________________________________________ Fire Sentry Corporation Document No. 1508-002 - Rev B © Copyright 2009 All Rights Reserved...
- Page 2 Near Band IR, NearBand IR, QuadBand IR, Room Sentry, RS, RS2, SM2, SM3, SS, SS2, SS2X, SS2-A, SS3, SS3-A, SS3X, SS4, SS4-A, SS4X, SnapShot, SLR-BIT, SuperBus, SuperSentry, System 2000, Tri- Mode Plot, QuadBand Triple IR Plus, TriBand, Tri-Band, “FS & FSC triangle logo’s”, WBIR, Wide Band Infrared, WideBand IR, Wide Band IR are Trademarks of Fire Sentry Corporation (FSC), Yorba Linda, California.
-
Page 3: Table Of Contents
Cleaning Windowed Enclosures and Detectors Model SS3 Detector Detector Repair SECTION 4 DETECTOR DATA Table 1: Model SS3 Detector Connectors - Pinouts Mechanical Layouts Model SS3 Detector Mounting Brackets Model SS3-A and SS3-AN Detectors MODEL SS3-AB AND SS3-ABN DETECTORS INDEX... -
Page 4: Familiarization
The Model SS3 Detectors are micro-computerized devices. The Detectors’ logic "brain" alarms to fires quickly. There is one LED on the Model SS3 Detectors that indicate the state of the Detector. If the LED blinks approximately every 10 seconds, then the Detector is in Normal Operation When a Model SS3 Detector alarms to a fire, it energizes its Fire relay and turns on its red LED. -
Page 5: Installation
Power Supply Considerations The Model SS3 Detectors use 12 or 24 volts DC at a maximum current of 40 milliamps. Make sure that the Panel's power supply can handle the current load of the total number of Model SS3 Detectors connected to it. -
Page 6: Wiring As Standalone
DO NOT CONNECT ANY WIRES TO J1 - Pin 2 or J1 - Pin 3. Do NOT over tighten or the screws may strip or break. Refer to Figure 4, Model SS3 Detector Wiring. Pin 1... - Page 7 SS3-A, SS3-AN, SS3-AB, SS3-ABN Electro-Optical Fire Detectors Page 4 Installation and Operations Guide _____________________________________________________________________________ Figure 1 Model SS3 Detector Connection Diagrams Figure 2 Model SS3 Detectors Wiring ____________________________________________________________________________________________________________________ Fire Sentry Corporation Document No. 1508-002 - Rev B © Copyright 2009...
-
Page 8: Maintenance And Troubleshooting
ODEL ETECTOR If a Model SS3 Detector must be shipped back to the factory for repair, it MUST be packed in static protected material. An RMA (Return Material Authorization) is required for all returns to the factory. Contact Customer Service for an RMA number before shipping a unit back to the factory. -
Page 9: Detector Data
Page 6 Installation and Operations Guide _____________________________________________________________________________ SECTION 4 DETECTOR DATA Table 1: Model SS3 Detector Connectors - Pinouts DETECTOR INPUT POWER FIRE RELAY 1 DC Return or Ground (-) 5 Fire Relay EOL Resistor (10K ohms) 2 FireBus Communication (-) -
Page 10: Mechanical Layouts
SS3-A, SS3-AN, SS3-AB, SS3-ABN Electro-Optical Fire Detectors Page 7 Installation and Operations Guide _____________________________________________________________________________ Mechanical Layouts P.N. 188424 for SS3-A and SS3-AN P.N. 188424(B) for SS3-AB and SS3-ABN (Included with Detector) (Included with Detector) Figure 3 Model SS3 Detector Mounting Brackets... -
Page 11: Model Ss3-A And Ss3-An Detectors
SS3-A, SS3-AN, SS3-AB, SS3-ABN Electro-Optical Fire Detectors Page 8 Installation and Operations Guide _____________________________________________________________________________ Figure 4 Model SS3-A and SS3-AN Detectors Figure 5 Model SS3-AB and SS3-ABN Detectors ____________________________________________________________________________________________________________________ Fire Sentry Corporation Document No. 1508-002 - Rev B © Copyright 2009... -
Page 12: Index
SS3-A, SS3-AN, SS3-AB, SS3-ABN Electro-Optical Fire Detectors Page 9 Installation and Operations Guide _____________________________________________________________________________ INDEX Cleaning Products, 5 False Alarms, 1 Layout Planning, 2 See Detector, 1 FireBus, 1 Stand-Alone, 1 FireBus Wiring, 2 Detector FireLogic, 1 Maintenance, 5 Cleaning, 5... - Page 13 Thank you for reading this data sheet. Please contact us for a quotation: Head Office (UK) Switzerland Office P.O. Box 2124 Zugerstrasse 46 Chelmsford 6314 Unterägeri Essex CM1 3UP England Switzerland Tel: +44 (0)1245 600 560 Tel: +41 41 541 5877 Fax: +44 (0)1245 600 030 Fax: +41 41 541 5878 Email:...
