Operating Guide
TS-700 Series Digital Indicators
Includes Appendix for Scale Technicians
Set Up • Calibration • Connectivity
TS 700-MS
Series 2
0
TS 700-SS
Series 3
Compatible with DataLog
TS 700-WB
TM
Scale-to-PC Data Logging Software
OG Version 2.0_03-15-17

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the TS-700 Series and is the answer not in the manual?

Questions and answers

Bob Gerring
May 15, 2025

How to change the battery?

0

Subscribe to Our Youtube Channel

Related Manuals for Triner Scale TS-700 Series

Summary of Contents for Triner Scale TS-700 Series

  • Page 1 Operating Guide TS-700 Series Digital Indicators Includes Appendix for Scale Technicians Set Up • Calibration • Connectivity TS 700-MS Series 2 TS 700-SS Series 3 TS 700-WB Compatible with DataLog Scale-to-PC Data Logging Software OG Version 2.0_03-15-17...
  • Page 2 Do not make any connections without powering off the indicator. DANGER Electric shock risk. Take necessary precautions to avoid risk of shock. Triner Scale & Mfg.Co., Inc. 8411 Hacks Cross Road Olive Branch, MS 38654 (800) 238-0152 www.trinerscale.com © 2016-2020 Triner Scale. All rights reserved.

  • Page 3: Table Of Contents

    Operating Guide | TS-700 Series Table of Contents Specifications TS-700 MS, SS and WB ..........2 Quick Start: Connecting and Powering On TS-700 MS................3 TS-700 SS ................5 TS-700 WB ...............7 Operation Keys and Functions: TS-700 MS, SS and WB....9 Parameters and Settings How to Access and Adjust Parameters ......12...

  • Page 4: Specifications

    Kg/lb Display weight in pounds or kilograms Gross/Tare Tare container weight, display gross or net weight Zero Returns the indicated weight to “0” Print Prints receipt (requires optional printer) PC connectivity requires Triner Scale’s DataLog PC™ software. *requires adjustment of parameter settings...

  • Page 5: Quick Start: Connecting And Powering On Ts-700 Ms

    Operating Guide | TS-700 Series Quick Start: Connecting & Powering On TS-700 MS Connect Weighing Platform Cable Attach the home run cable from the weighing platform to the loadcell port located on the underside of the digital indicator. Connect Any Optional Devices...
  • Page 6 Operating Guide | TS-700 Series Quick Start: Connecting & Powering On TS-700 MS device to the RS-232 port located on the underside of the digital indicator. Power on the device. Connect AC Adapter Plug the AC adapter included with the digital indicator into the 9VDC 1200ma port located on the underside of the digital indicator.
  • Page 7 Operating Guide | TS-700 Series Quick Start: Connecting & Powering On TS-700 SS Connect Weighing Platform Cable Attach the home run cable from the loadcell port to the weighing platform junction box. Refer to installation instructions provided with the Triner...
  • Page 8 Operating Guide | TS-700 Series Quick Start: Connecting & Powering On TS-700 SS Connect Any Optional Devices Referring to the manual provided with optional device (such as a receipt printer), connect the device to the RS-232 port located on the underside of the digital indicator.
  • Page 9 Operating Guide | TS-700 Series Quick Start: Connecting & Powering On TS-700 WB Connect the Weigh Bar Cables Attach the home run cables to the loadcell ports and to the weigh bars. For weigh bar set up, refer to the...
  • Page 10 Operating Guide | TS-700 Series Quick Start: Connecting & Powering On TS-700 WB Connect Any Optional Devices Referring to the manual provided with optional device (such as a receipt printer), connect the device to the RS-232 port located on the underside of the digital indicator.

  • Page 11: Operation

    Operating Guide | TS-700 Series Operation KEYS AND FUNCTIONS: TS-700 MS, SS & WB KEY FUNCTION/OPERATION On/Off Press and hold for 2+ seconds to operate. Hold Livestock Hold (animal weight hold): If set up for livestock weighing, the animal’s weight will automatically hold.
  • Page 12 Operating Guide | TS-700 Series KEY FUNCTION/OPERATION Total To Add Weights: With weight on scale, press the Total key to place weight and count in memory. Remove NOTE: weight, place next item on scale, press Total to Before placing add weight to total weight and total count.
  • Page 13 Operating Guide | TS-700 Series KEY FUNCTION/OPERATION Gross For use after a TARE weight has been stored in the indicator. Press key to toggle view between gross and net weight. PLEASE NOTE that there may be a momentary pause in the display when going from gross to tare weight.

  • Page 14: Parameters And Settings

    Operating Guide | TS-700 Series Parameters and Settings CAUTION: Use care when accessing and adjusting your indicator’s parameters. Several parameters can be accessed that, if altered, will change your indicator’s operations. HOW TO ACCESS AND ADJUST THE TS-700 MS PARAMETERS Press and hold down the PRINT and HOLD keys.
  • Page 15 Operating Guide | TS-700 Series Press the kg-lb/left arrow key to move the active digit from the 6 to the 0 (the 0 will flash). Use the Zero/up arrow key to increase the 0 to 1 (C16 will display). Press the Print/enter key.

  • Page 16: Parameters Charts

    Operating Guide | TS-700 Series PARAMETERS CHART (For calibration parameters, see Appendix for Scale Technicians, page A-4) PARAMETER FUNCTION OPTIONS Warning tone 0 = Disable warning tone 1 = warning tone on Automatic 0 = Disable auto off Power-off 10 = Power off in 10 minutes.
  • Page 17 Operating Guide | TS-700 Series PARAMETER FUNCTION OPTIONS Inner Code Enter C15 to check the display inner code. Date Set the date, from left to right: year/month/day Time Set the time from left to right: hour/min./sec. Communication 0 = Serial interface data...
  • Page 18 Operating Guide | TS-700 Series PARAMETER FUNCTION OPTIONS Automatic Zero: 0 = Disable zero CAUTION: tracking range tracking Changing 0.5 = ±0.5d these 1.0 = ±1.0d parameters will 2.0 = ±2.0d effect the 3.0 = ±3.0d indicator’s 4.0 = ±4.0d performance.
  • Page 19 Operating Guide | TS-700 Series PARAMETER FUNCTION OPTIONS Standstill time 0 = quick CAUTION: 1 = medium Changing 2 = slow these parameters will affect the indicator’s performance. Standstill range 1 = 1d 2 = 2d 5 = 5d 10 = 10d...
  • Page 20 Operating Guide | TS-700 Series PARAMETER FUNCTION OPTIONS OPTIONAL 0 = Close relay output Relay output 1 = Open relay output setting function 1 2 = Open relay output function 2 3 = Reserved menu RESERVED ------- -------- RESERVED Gravity of C36 = 9.7000 -- 9.9999...

  • Page 21: Compatible Receipt Printers Mp-20 Model & Sp-500 Model Printers

    Operating Guide | TS-700 Series Using A Receipt Printer SP-500 printer receipt Sequential ID.NO. SP-500 model only To print receipts with an optional printer: - With power off, attach the printer cable to the connector socket on the underside of the indicator.

  • Page 22: Appendix For Scale Technicians

    Operating Guide | TS-700 Series Appendix For Scale Technicians Calibrating a TS-700 Series Indicator NOTICE: The TS-700 SS, MS & WB are NTEP Class III Legal for Trade approved and certified. Unlocking the calibration parameters is not allowed by persons other than qualified scale technicians.
  • Page 23 Operating Guide | TS-700 Series Appendix For Scale Technicians Calibration Switch, TS-700 MS: Remove the screws and the back plate of the enclosure. A white-capped calibration switch is located at the bottom left corner of the circuit board. Press the switch fully in and release.

  • Page 24: Calibration Procedure

    Operating Guide | TS-700 Series Appendix For Scale Technicians A small calibration switch is located at the bottom left corner of the circuit board. Move the switch to the “On” position. Close the enclosure. ALL TS-700 MODELS: After enabling access to...
  • Page 25 Operating Guide | TS-700 Series Appendix For Scale Technicians PARAMETER FUNCTION OPTIONS Default weighing 1 = kg unit 2 = lb Description: With C01 flashing, press the key, then use the up or down arrow keys to change the parameter setting as needed.
  • Page 26 Operating Guide | TS-700 Series Appendix For Scale Technicians PARAMETER FUNCTION OPTIONS Graduations 1 = one unit 2 = two units 5 = five units 10 = ten units 20 = twenty units 50 = fifty units Description: With C03 flashing, press the...
  • Page 27 Operating Guide | TS-700 Series Appendix For Scale Technicians PARAMETER FUNCTION OPTIONS Zero Calibration 0 = skip zero calibration 1 = proceed with zero calibration Description: With C05 flashing, press the key, then use the up arrow key to change the 0 parameter setting to 1.
  • Page 28 Operating Guide | TS-700 Series Appendix For Scale Technicians PARAMETER FUNCTION OPTIONS Calibration 0 = skip calibration 1 = proceed with calibration Description: With C06 flashing, press the key, then use the up arrow key to change the 0 parameter setting to 1.
  • Page 29 Operating Guide | TS-700 Series Appendix For Scale Technicians PARAMETER FUNCTION OPTIONS FACTORY 0 = skip reset to factory CAUTION!! RESET… defaults Erases all 1 = proceed with reset to custom defaults settings! Description: To reset to factory defaults, change the 0 setting to 1 and press the key.

  • Page 30: Load Cell Connections

    Operating Guide | TS-700 Series Appendix For Scale Technicians Load Cell Connections The indicator can connect with a maximum of eight (8) 350Ω load cells, 4 wire or 6 wire configurations. Excitation voltage for the load cell is 5VDC, the maximum output current is 120mA.

  • Page 31: Ts-700 Ms

    Operating Guide | TS-700 Series Appendix For Scale Technicians Serial Port Connection RS232 CONNECTION TS-700 MS The RS232 DB9 serial port can be utilized to connect the indicator to a peripheral device such as a printer or remote display, or to interface the indicator with a PC.

  • Page 32: Ts-700 Ss

    Operating Guide | TS-700 Series Appendix For Scale Technicians TS-700 SS The 3-wire terminal block located on the main board can be utilized to connect the indicator to a peripheral device such as a printer or remote display, or to interface the indicator with a PC.

  • Page 33: Remote Display Format

    Operating Guide | TS-700 Series Appendix For Scale Technicians Data Output Formats REMOTE DISPLAY FORMAT State A Bits: 0,1,2 Decimal point position XXXXXX0 XXXXXXX XXXXX-X XXXX-XX XXX-XXX Bits: 3,4 Division State B BITS FUNCTION Bits0 Gross = 0, net=1 Bits1...

  • Page 34: Pc Computer Continuous Sending Format

    Operating Guide | TS-700 Series Appendix For Scale Technicians PC COMPUTER CONTINUOUS SENDING FORMAT Data Weight status: ST = standstill US = not standstill OL = overload Weight mode: GS = gross mode NT = net mode Weight of positive and negative, “+”...

  • Page 35: Serial Interface Reception Command

    Operating Guide | TS-700 Series Appendix For Scale Technicians SERIAL INTERFACE PC COMMAND REQUESTS RS232COM serial interface can receive simple ASCII commands. Command word and role as follows: Command Name Function TARE Save and clear tare ZERO Zero gross weight...

  • Page 36: Error Codes

    Operating Guide | TS-700 Series Appendix For Scale Technicians Error Codes ERROR CAUSE SOLUTION 1. Overloaded 1. Reduce the weight. condition. 2. Check load cell 2. Wrong connection uuuuuu connection at 3. Inspect load cell. Check load cell. the input and output 3.
  • Page 37 Operating Guide | TS-700 Series Appendix For Scale Technicians ERROR CAUSE SOLUTION During calibration, the After the platform is ERR4 stable, start calibration. signal is unstable. ERR5 Circuitry error Replace the PCB. Check all cables and ERR6 Zero point error connections.
  • Page 38 Operating Guide | TS-700 Series Appendix For Scale Technicians PARAMETER FUNCTION DEFAULT Hold function Disable kg/lb conversion Upper limit alarm 000000 Under limit alarm 000000 Inner code ---- Date setting ---- Time setting ---- Serial interface data output Serial interface Baud rate...
  • Page 39 Operating Guide | TS-700 Series Appendix For Scale Technicians PARAMETER FUNCTION DEFAULT Dynamic filter Noise filter Print format Analog signal options 4~20mA testing Relay output setting Reserved Reserved Calibration location gravity 9.7936 Destination gravity 9.7936 Version No. ---- Reserved menu...
  • Page 40 Triner Scale & Manufacturing Co. Inc. 8411 Hacks Cross Road Olive Branch, MS 38654 (800) 238-0152 www.trinerscale.com...
