Hello! Let's install a ZAURA System.
Zilog's ZAURA RF Wireless occupancy detector energy management system is designed for easy plug‐and‐play installation. This guide is
designed to assist professional lighting systems installers to perform a typical ZAURA System installation which will detect occupancy in a
room and switch the starter‐based lighting on and off without the need for control wiring. For greater detail about each of the following
steps, refer to the ZAURA Installation Guide (UM0229).
Step 1. Assemble your tools. You'll need the following items:
• Screwdriver
• Ladder
• Pen, Pencil or Marker
• Standard electric drill and bits (for concrete, an impact drill)
• Small slot screwdriver (for changing Master DIP Switch positions)
• Tape measure
• Appropriate tools to access starter(s) in luminaries
Step 2. Determine the location of Standard Masters (and Range
Extenders, if required).
Step 3. Determine luminary configuration.
ZAURA
RF Wireless Lighting Control
™
Professional Installer's Reference Guide
Copyright ©2011 Zilog
Step 4. Inventory your parts. A typical installation will require as
many starters as there are light fixtures in the room.
If the room is any larger than six meters square, you
Note
:
many need a 2nd Master unit. See the ZAURA Instal‐
lation Guide for details.
Step 5. Open the Master Unit by removing the retaining screw from
the side of the Detector body. Turn the base plate until the arrows
on the Detector body and the base plate align. Remove the Detector
body and lens cover from the base.
Step 6. Mount base plate(s) to the ceiling in the location(s) you
determined in Step 2 using the screws or the double‐sided tape
1
provided.
Step 7. To configure a ZAURA Master, set the Master type switch to
the Standard (OFF, OFF) position.
1
The double‐sided tape is non‐permanent and is recommended only for test‐
ing your configuration prior to permanently affixing your ZAURA Master.
®
, Inc. All rights reserved.
www.zilog.com
QS008001‐0311
Advertisement
Related Manuals for ZiLOG ZAURA RF
Summary of Contents for ZiLOG ZAURA RF
- Page 1 ZAURA RF Wireless Lighting Control ™ Professional Installer’s Reference Guide QS008001‐0311 Hello! Let’s install a ZAURA System. Zilog’s ZAURA RF Wireless occupancy detector energy management system is designed for easy plug‐and‐play installation. This guide is designed to assist professional lighting systems installers to perform a typical ZAURA System installation which will detect occupancy in a room and switch the starter‐based lighting on and off without the need for control wiring. For greater detail about each of the following steps, refer to the ZAURA Installation Guide (UM0229). Step 1. Assemble your tools. You’ll need the following items: Step 4. Inventory your parts. A typical installation will require as many starters as there are light fixtures in the room. • Screwdriver • Ladder • Pen, Pencil or Marker If the room is any larger than six meters square, you Note • Standard electric drill and bits (for concrete, an impact drill) many need a 2nd Master unit. See the ZAURA Instal‐ lation Guide for details. • Small slot screwdriver (for changing Master DIP Switch positions) • Tape measure • Appropriate tools to access starter(s) in luminaries Step 5. Open the Master Unit by removing the retaining screw from the side of the Detector body. Turn the base plate until the arrows Step 2. Determine the location of Standard Masters (and Range on the Detector body and the base plate align. Remove the Detector Extenders, if required). body and lens cover from the base. Step 6. Mount base plate(s) to the ceiling in the location(s) you determined in Step 2 using the screws or the double‐sided tape provided.
- Page 2 ™ ZAURA RF Wireless Lighting Control Quick Start Guide Step 8. Make sure the mode is set to Normal Operation (i.e., DIP Step 11. Adjust light and occupancy sensitivity POT, if required. switches 1, 2 and 3 are in the OFF position). Step 9. Make sure the Dim Control is set to Normal Operation (i.e., DIP switches 4 and 5 are in the OFF position). Step 12. Install a Lithium 3V Type CR123 battery in either battery slot of the Master. If the Master will be associated with any Range Extenders, Zilog recommends installing two batteries. The Master will initialize for a period of up to one minute. Step 13. If a Range Extender is required, set the Master type switch to Range Extender (OFF, ON) position, as shown in the figure in Step 7. If no Range Extenders are required in your installation, skip to Step 17. Step 14. Set DIP switches 1 through 8 to match the Master; refer to the figure in Step 11. Step 15. Adjust the Occupancy Sensitivity POT (if required) and install a Lithium 3V Type CR123 battery in either battery slot of the Step 10. Set the turn‐off delay to the required value (the base plate of the Range Extender. recommended setting is 5 minutes). Step 16. Associate the Range Extender to the Master by pressing the Dimming or Non‐Dimming Associate button on the Master. The Master will attempt association for a period of 30 seconds. Please proceed to the next page. QS008001‐0311 Page 2 of 3...
- Page 3 Master by pressing the Associate Dimmer button. The Master will Step 27. Mount the Range Extenders (if any) to their designated attempt association for a period of 30 seconds. base plates; see steps 25 and 26. Your installation is now complete! Step 20. Verify the association of all ZAURA Virtual Dimming Starters: DO NOT USE THIS PRODUCT IN LIFE SUPPORT SYSTEMS. Warning: a. Change the mode to Toggle Dimming Lamps by sliding DIP Switch 2 to the ON position. LIFE SUPPORT POLICY b. Press the Set Mode button. All luminaries that are associated ZILOG’S PRODUCTS ARE NOT AUTHORIZED FOR USE AS CRITICAL COMPONENTS IN LIFE SUP‐ as Virtual Dimming should turn off. PORT DEVICES OR SYSTEMS WITHOUT THE EXPRESS PRIOR WRITTEN APPROVAL OF THE PRESI‐ DENT AND GENERAL COUNSEL OF ZILOG CORPORATION. c. Press the Set Mode button a second time. The same luminar‐ Life support devices or systems are devices which (a) are intended for surgical implant into the body, or (b) support or sustain life and whose failure to perform when properly used in accor‐ ies should turn back on. dance with instructions for use provided in the labeling can be reasonably expected to result in d. Slide DIP Switch 2 to the OFF position to return the Master to a significant injury to the user. A critical component is any component in a life support device or system whose failure to perform can be reasonably expected to cause the failure of the life sup‐...
