- Page 1 Manual / Operating Instructions DOME Camera EC-750 Ex R. STAHL Camera Systems GmbH Adolf-Grimme-Allee 8 D 50829 Köln Version 01.01.10 Issue: 31.03.2017...
-
Page 2: Disclaimer
The terms and names used in this document are registered trademarks and/or products of the companies in question. Copyright © 2017 by R. STAHL Camera Systems GmbH. Subject to alterations. R. STAHL Camera Systems GmbH / HM_OI_Camera_EC_750_en_V_01_01_10.docx / 31.03.2017... -
Page 3: Specific Markings
Information highlighted by this symbol refers to a different DOCUMENTATION chapter or section in this manual or other documentation or a web-page. R. STAHL Camera Systems GmbH / HM_OI_Camera_EC_750_en_V_01_01_10.docx / 31.03.2017 Page 3 of 24... -
Page 4: Table Of Contents
EC-750 Ex DOME Camera connections 13.2.1 EC-750-aa-bb-PE 13.2.1.1 EC-750-aa-VI-PE connection 13.2.1.2 EC-750-aa-IP-PE connection Software function 14.1 EC-750-aa-VI-cc 14.1.1 Protocol 14.2 EC-750-aa-IP-cc 14.2.1 Protocol Maintenance, service 15.1.1 Servicing Troubleshooting R. STAHL Camera Systems GmbH / HM_OI_Camera_EC_750_en_V_01_01_10.docx / 31.03.2017 Page 4 of 24... - Page 5 Manual / Operating Instructions DOME Camera EC-750 Ex Table of contents Disposal 17.1 RoHS directive 2011/65/EC Declaration of EC conformity Release Notes R. STAHL Camera Systems GmbH / HM_OI_Camera_EC_750_en_V_01_01_10.docx / 31.03.2017 Page 5 of 24...
-
Page 6: Preface
18x optical zoom lens with a versatile video IP server or CVBS output, depending on the camera variant. R. STAHL Camera Systems GmbH / HM_OI_Camera_EC_750_en_V_01_01_10.docx / 31.03.2017 Page 6 of 24... -
Page 7: Technical Details
-20 °C to +60 °C with cable gland and T5 / T100°C Cable: 5.0 metre (+0.1) cable Power supply: 18…30 VDC, maximum 12 W R. STAHL Camera Systems GmbH / HM_OI_Camera_EC_750_en_V_01_01_10.docx / 31.03.2017 Page 7 of 24... -
Page 8: Ec-750-Aa-Vi-Cc
IP address filtering HTTPS encryption Web server: Live view access from web browser Pan / tilt commands and presets Image rotation and overlay capabilities (time, date, text) R. STAHL Camera Systems GmbH / HM_OI_Camera_EC_750_en_V_01_01_10.docx / 31.03.2017 Page 8 of 24... -
Page 9: Conformity To Standards
EN 61000-6-4 : 2007 Emission RoHS directive 2011/65/EU Classification Technical documentation assessment of electrical and electronic EN 50581 : 2012 products with respect to the restriction of hazardous substances R. STAHL Camera Systems GmbH / HM_OI_Camera_EC_750_en_V_01_01_10.docx / 31.03.2017 Page 9 of 24... -
Page 10: Certifications
II 2 D Ex tb IIIC T85°C Db, -20°C ≤ Ta ≤ +55°C II 2 D Ex tb IIIC T100°C Db, -20°C ≤ Ta ≤ +60°C R. STAHL Camera Systems GmbH / HM_OI_Camera_EC_750_en_V_01_01_10.docx / 31.03.2017 Page 10 of 24... -
Page 11: Permitted Maximum Values
1/4” CCD image sensor NTSC EC-750-NT-bb-cc EC-750-aa-VI-PE Analog CVBS output Cable output by certified stuffing box EC-750-aa-IP-PE Integrated IP server Cable output by certified stuffing box R. STAHL Camera Systems GmbH / HM_OI_Camera_EC_750_en_V_01_01_10.docx / 31.03.2017 Page 11 of 24... -
Page 12: Safety Advice
Incorrect or unauthorized use and non-compliance with the instructions in this manual will void any warranty on our part. No changes may be made to the EC-750 Ex DOME Camera or its components that compromise explosion protection ! R. STAHL Camera Systems GmbH / HM_OI_Camera_EC_750_en_V_01_01_10.docx / 31.03.2017 Page 12 of 24... -
Page 13: Zone
The earth/ground (PA) connector at the top of the EC-750 Ex DOME Camera housing must be connected to the equipotential bonding conductor of the hazardous area. The earth connector must have a minimum cross section of 4 mm². R. STAHL Camera Systems GmbH / HM_OI_Camera_EC_750_en_V_01_01_10.docx / 31.03.2017 Page 13 of 24... -
Page 14: Ec-750-Xxx Lens Coverage
11.3 EC-750-xxx lens coverage The drawing below represents the horizontal lens coverage of the EC-750 camera version both in the telephoto and the wide angle mode. R. STAHL Camera Systems GmbH / HM_OI_Camera_EC_750_en_V_01_01_10.docx / 31.03.2017 Page 14 of 24... -
Page 15: Horizontal Lens Coverage In Actual Figures
The installation of the EC-750 Ex DOME Camera should be in accordance to the shown drawings and including the solar protector. CAUTION The EC-750 Ex DOME Camera MUST be mounted vibration-free ! R. STAHL Camera Systems GmbH / HM_OI_Camera_EC_750_en_V_01_01_10.docx / 31.03.2017 Page 15 of 24... -
Page 16: Mechanical Dimensions
Manual / Operating Instructions DOME Camera EC-750 Ex Assembly and disassembly 12.3 Mechanical dimensions Plan view: Side view: R. STAHL Camera Systems GmbH / HM_OI_Camera_EC_750_en_V_01_01_10.docx / 31.03.2017 Page 16 of 24... -
Page 17: Operation
(White – 0.34 mm²) Rx A (Blue – 0.14 mm²) VIDEO - Koax (Purple – 0.14 mm²) VIDEO - GND (Green / Yellow – 0.6 mm²) Screen R. STAHL Camera Systems GmbH / HM_OI_Camera_EC_750_en_V_01_01_10.docx / 31.03.2017 Page 17 of 24... -
Page 18: Ec-750-Aa-Ip-Pe Connection
(Pink – 0.34 mm²) TxD (-) Ethernet (White – 0.14 mm²) RxD (+) connector RJ-45 (Grey – 0.14 mm²) RxD (-) (Green / Yellow – 0.6 mm²) Earth R. STAHL Camera Systems GmbH / HM_OI_Camera_EC_750_en_V_01_01_10.docx / 31.03.2017 Page 18 of 24... -
Page 19: Software Function
The settings at the AXIS board 282 must not be changed ! These NOTICE settings are the same as at the camera variant EC-750-aa-VI-cc. The Device ID MUST BE 1 ! R. STAHL Camera Systems GmbH / HM_OI_Camera_EC_750_en_V_01_01_10.docx / 31.03.2017 Page 19 of 24... -
Page 20: Maintenance, Service
In the case of Cameras (category 9 – monitoring and controlling devices) a transitional period applies until 22.07.2017, after which the banned substances listed in RoHS 2011/65/EC directive apply to all devices newly put on the market. R. STAHL Camera Systems GmbH / HM_OI_Camera_EC_750_en_V_01_01_10.docx / 31.03.2017 Page 20 of 24... -
Page 21: Declaration Of Ec Conformity
Manual / Operating Instructions DOME Camera EC-750 Ex Declaration of EC conformity 18 Declaration of EC conformity R. STAHL Camera Systems GmbH / HM_OI_Camera_EC_750_en_V_01_01_10.docx / 31.03.2017 Page 21 of 24... -
Page 22: Release Notes
Removal of CKT certification and its data Certificates listed into a new document "CE_Camera_EC_750…" Addition of "note to certificates" in section "preface" Layout- and formale corrections R. STAHL Camera Systems GmbH / HM_OI_Camera_EC_750_en_V_01_01_10.docx / 31.03.2017 Page 22 of 24... - Page 24 R. STAHL Camera Systems GmbH Adolf-Grimme-Allee 8 D 50829 Köln Phone: (switchboard) +49 (0) 221 76 806 - 1200 (hotline) - 5000 Fax: - 4200 E-mail: (switchboard) office@stahl-camera.de (hotline) support@stahl-camera.de www.stahl.de www.stahl-camera.de...
