Manual / Operating Instructions
DOME Camera EC-750 Ex
R. STAHL HMI Systems GmbH
Im Gewerbegebiet Pesch 14
Version
Issue:
50767 Köln
01.01.06
03.11.2010

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the EC-750 Series and is the answer not in the manual?

Questions and answers

Related Manuals for Stahl EC-750 Series

Summary of Contents for Stahl EC-750 Series

  • Page 1 Manual / Operating Instructions DOME Camera EC-750 Ex R. STAHL HMI Systems GmbH Im Gewerbegebiet Pesch 14 50767 Köln Version 01.01.06 Issue: 03.11.2010...

  • Page 2: Table Of Contents

    Software function 13.1 EC-750-aa-VI-cc 13.1.1 Protocol 13.2 EC-750-aa-IP-cc 13.2.1 Protocol Maintenance, service 14.1.1 Servicing Troubleshooting Disposal 16.1.1 ROHS directive 2002/95/EC Certificates 17.1 Declaration of EC conformity 17.1.1 EC-750-aa-bb-PE Page 2 of 24 R. STAHL HMI Systems GmbH / HM_OI_Camera_EC_750_en_V_1_01_06.docx / 03.11.2010...
  • Page 3 Manual / Operating Instructions DOME Camera EC-750 Ex Table of contents 17.1.2 EC type examination certificate Release Notes R. STAHL HMI Systems GmbH / HM_OI_Camera_EC_750_en_V_1_01_06.docx / 03.11.2010 Page 3 of 24...

  • Page 4: Preface

    The EC-750 Ex DOME Cameras have a compact volume with a tilt/rotate viewing head. The cameras have a high quality night and day 18x optical zoom lens with a versatile video IP server or CVBS output, depending on the camera variant. Page 4 of 24 R. STAHL HMI Systems GmbH / HM_OI_Camera_EC_750_en_V_1_01_06.docx / 03.11.2010...

  • Page 5: Technical Details

    -20°C to +55°C with cable gland and T6 / T85° -20°C to +60°C with cable gland and T5 / T100°  Cable: 5.0 metre (+0.1) cable  Power supply: 18…30 VDC, maximum 12 W R. STAHL HMI Systems GmbH / HM_OI_Camera_EC_750_en_V_1_01_06.docx / 03.11.2010 Page 5 of 24...

  • Page 6: Ec-750-Aa-Vi-Cc

    EN 60079-1 : 2004 EN 50281-1-1 : 1998 EN 61000-6-2 : 2001 EN 61000-6-4 : 2001 EN 61000-3-2 : 2000 EN 61000-3-3 : 1995 + A1 (2001) Page 6 of 24 R. STAHL HMI Systems GmbH / HM_OI_Camera_EC_750_en_V_1_01_06.docx / 03.11.2010...

  • Page 7: Product Identification

    EC-750-PA-bb-cc 1/4” CCD image sensor NTSC EC-750-NT-bb-cc EC-750-aa-VI-PE Analog CVBS output Cable output by certified stuffing box EC-750-aa-IP-PE Integrated IP server Cable output by certified stuffing box R. STAHL HMI Systems GmbH / HM_OI_Camera_EC_750_en_V_1_01_06.docx / 03.11.2010 Page 7 of 24...

  • Page 8: Safety Advice

    The EC-750 Ex DOME Camera may only be installed and operated in an undamaged, dry and clean condition ! Page 8 of 24 R. STAHL HMI Systems GmbH / HM_OI_Camera_EC_750_en_V_1_01_06.docx / 03.11.2010...

  • Page 9: Zone

    The earth/ground (PA) connector at the top of the EC-750 Ex DOME Camera housing must be connected to the equipotential bonding conductor of the hazardous area. The earth connector must have a minimum cross section of 4 mm². R. STAHL HMI Systems GmbH / HM_OI_Camera_EC_750_en_V_1_01_06.docx / 03.11.2010 Page 9 of 24...

  • Page 10: Ec-750-Xxx Lens Coverage

    Installation 10.3 EC-750-xxx lens coverage The drawing below represents the horizontal lens coverage of the EC-750 camera version both in the telephoto and the wide angle mode. Page 10 of 24 R. STAHL HMI Systems GmbH / HM_OI_Camera_EC_750_en_V_1_01_06.docx / 03.11.2010...

  • Page 11: Horizontal Lens Coverage In Actual Figures

    24.9 32.1 39.6 Consequently, an object of a size between 0.05 m and 0.9 m can be viewed at a distance to the camera of 1 m. R. STAHL HMI Systems GmbH / HM_OI_Camera_EC_750_en_V_1_01_06.docx / 03.11.2010 Page 11 of 24...

  • Page 12: Assembly And Disassembly

    The installation of the EC-750 Ex DOME Camera should be in accordance to the shown drawings and including the solar protector.  The EC-750 Ex DOME Camera MUST be mounted vibration-free ! Page 12 of 24 R. STAHL HMI Systems GmbH / HM_OI_Camera_EC_750_en_V_1_01_06.docx / 03.11.2010...

  • Page 13: Mechanical Dimensions

    Manual / Operating Instructions DOME Camera EC-750 Ex Assembly and disassembly 11.3 Mechanical dimensions Plan view: Side view: R. STAHL HMI Systems GmbH / HM_OI_Camera_EC_750_en_V_1_01_06.docx / 03.11.2010 Page 13 of 24...

  • Page 14: Operation

    When operating the EC-750 Ex DOME Camera, particular care shall be taken that: the EC-750 Ex DOME Camera has been properly installed according to instructions, the camera is undamaged, all screws are tightened fast. Page 14 of 24 R. STAHL HMI Systems GmbH / HM_OI_Camera_EC_750_en_V_1_01_06.docx / 03.11.2010...

  • Page 15: Ec-750 Ex Dome Camera Connections

    Tx485 B (half B) (pink – 0.34 mm²) Rx485 B / Tx232 (white – 0.34 mm²) Rx485 A / Rx232 (blue – 0.14 mm²) VIDEO (green/yellow) screen R. STAHL HMI Systems GmbH / HM_OI_Camera_EC_750_en_V_1_01_06.docx / 03.11.2010 Page 15 of 24...

  • Page 16: Ec-750-Aa-Ip-Pe Connection

    TxD (+) (pink – 0.34 mm²) TxD (-) Ethernet (white – 0.14 mm²) RxD (+) connector RJ-45 (grey – 0.14 mm²) RxD (-) (green/yellow – 0.6 mm²) earth Page 16 of 24 R. STAHL HMI Systems GmbH / HM_OI_Camera_EC_750_en_V_1_01_06.docx / 03.11.2010...

  • Page 17: Software Function

    2400 baud 8 data bit 1 stop bit no parity The bus address of the camera is 1. These address can only be changed by R. STAHL HMI Systems GmbH ! 13.2 EC-750-aa-IP-cc The camera variants EC-750-aa-IP-cc contains an integrated IP server. The video and data transmission is done on an Ethernet connection via IP.

  • Page 18: Maintenance, Service

    The prohibition of hazardous substances as detailed in directive 2002/95/EC (ROHS) does not apply to electronic equipment of categories 8 and 9, and is therefore not applicable to the equipment described in these operating instructions. Page 18 of 24 R. STAHL HMI Systems GmbH / HM_OI_Camera_EC_750_en_V_1_01_06.docx / 03.11.2010...

  • Page 19: Certificates

    Manual / Operating Instructions DOME Camera EC-750 Ex Certificates 17 Certificates 17.1 Declaration of EC conformity 17.1.1 EC-750-aa-bb-PE R. STAHL HMI Systems GmbH / HM_OI_Camera_EC_750_en_V_1_01_06.docx / 03.11.2010 Page 19 of 24...
  • Page 20 Manual / Operating Instructions DOME Camera EC-750 Ex Certificates 17.1.2 EC type examination certificate Page 20 of 24 R. STAHL HMI Systems GmbH / HM_OI_Camera_EC_750_en_V_1_01_06.docx / 03.11.2010...
  • Page 21 Manual / Operating Instructions DOME Camera EC-750 Ex Certificates R. STAHL HMI Systems GmbH / HM_OI_Camera_EC_750_en_V_1_01_06.docx / 03.11.2010 Page 21 of 24...
  • Page 22 Manual / Operating Instructions DOME Camera EC-750 Ex Certificates Page 22 of 24 R. STAHL HMI Systems GmbH / HM_OI_Camera_EC_750_en_V_1_01_06.docx / 03.11.2010...
  • Page 23 Inclusion of protocol information in section "Software function" Stylistic changes Camera version "ROTA" removed Version 01.01.05 Correction of connection camera variant EC-750-aa-IP-PE Version 01.01.06 Inclusion of section 10.3 "EC-750-xxx lens coverage" R. STAHL HMI Systems GmbH / HM_OI_Camera_EC_750_en_V_1_01_06.docx / 03.11.2010 Page 23 of 24...
  • Page 24 R. STAHL HMI Systems GmbH Im Gewerbegebiet Pesch 14 D-50767 Köln Phone: (switchboard) +49/(0)221/ 5 98 08 - 200 (hotline) - 59 Fax: - 260 E-mail: (switchboard) office@stahl-hmi.de (hotline) support@stahl-hmi.de www.stahl.de www.stahl-hmi.de...
