Southwest Windpower, Inc.
Renewable Energy Made Simple
Owners Manual
Installation, Operation and Maintenance
WHISPER WIND GENERATORS
MODEL Whisper 200
For the *NEW* Whisper Controller
Southwest Windpower, Inc.
1801 West Route 66
Flagstaff, Arizona 86001
Phone: (928)-779-9463
Fax: (928)-779-1485
Email: info@windenergy.com
Web page: http://www.windenergy.com
© January 2005 Southwest Windpower , Inc
All Right Reserved
WIND GENERATOR SERIAL NUMBER ________________
