Simplicity LEGACY 2000 Parts Manual page 7

Frame & Transaxle Group
REF NO PART NO.
41 1930545SM
42 1716256SM
43 1700814SM
44 1921319SM
45 1931704SM
46 1916964SM
47 1923341SM
Footnotes
The above parts group applies to the following Mfg. Nos.:
1693112 - Legacy
1693120 - Legacy
1693130 - 2024D
1693138 - 2924D
1693446 - 2924D
1693576 - Legacy
© Copyright 2009 by Briggs & Stratton Corporation
Milwaukee, WI, USA. All rights reserved
QTY. DESCRIPTION
1 SET SCREW, 1/4-20 x 5/16
1 SHAFT & HUB, Fan
1 FAN
1 WASHER, Plain, 1/4
1 LOCKWASHER, Dished, 1/4
1 LOCKWASHER, 1/4
1 CAPSCREW, Hex Hd, 1/4-20 x 3/4
1693738 - Legacy
7
TP 400-2215-B-LG-SMA
