Simplicity Lecacy Parts Manual page 11

Front Axle & Steering Group
REF NO PART NO.
41 2832577SM
42 1715762SM
43 1924361SM
44 1960286SM
45 1687103SM
46 1701011SM
Footnotes
Note* See Service Parts for Hydraulic Steering Unit - SERVICE PARTS
Note* See Service Parts for Tilt Assembly - SERVICE PARTS
The above parts group applies to the following Mfg. Nos.:
1692870 - Legacy
1692871 - Legacy
1692872 - Legacy
1693114 - Legacy
1693116 - Legacy
1693118 - Legacy
© Copyright 2009 by Briggs & Stratton Corporation
Milwaukee, WI, USA. All rights reserved
QTY. DESCRIPTION
1 RING, Retaining #98
2 SPACER, Tube Axle
2 WASHER, 1/2
2 CAPSCREW, Hex Head, 1/2-13 x 3-1/2
1 SPACER, Axle Pivot
2 TIE
1693124 - 2020
1693126 - 2025
1693128 - 2020LC
1693132 - 2920
1693134 - 2925
1693136 - 2920LC
1693219 - Legacy
1693220 - 2920
1693221 - 2020
1693250 - Legacy
1693561 - Legacy
1693562 - 2025
11
1693563 - 2925
1693764 - Legacy
1693769 - 2023H
1693770 - 2923H
1693771 - Legacy
TP 400-2155-C-LG-SMA
