Quick Start

Getting to Know the PS100

Getting to Know the PS100
The graphic below points out key a ributes of the PS100.
Source Selector
Active Source Indicator
Connect Sources Devices Here

Front View

Front View
Front View
IR (Infra-Red) Sensor
Stereo Audio Output
Source "Port"

Back View

Back View
Back View
USB Firmware Update
Display Output
EDID Resolution Select

Connections

Connections
Inputs and Outputs. Using the graphic above, connect the source devices to the ports labeled,
"Connect Source Devices Here", as a reference and the display at loca on, "Display Output",
port. Connect audio, if applicable.
Power. Connect the DC power supply to the loca on, "DC/5V", and the other end to a 110V/
VAC power socket. The system LED will illuminate just below and to the le of the DC/5V
loca on.
PS100 Quick Start Guide
Page 1
