Connect Fans To Network

CAT5 Cable (15 ft)
CAT5 Cable
(100 ft)
Controller
Instructions:
1. Refer to the fan installation manual(s) for fan installation instructions. Fans that are ordered for
networks are labeled with their assigned addresses. Take note of the addresses and ensure that
the fans are installed in the desired locations.
2. Mount the controller in the desired location.
3. Connect all fans as described in the previous pages. Ensure that the 15 ft CAT5 cables are
connected directly to the fans.
4. Review safety and caution information in the fan installation manual(s) and apply power to all of
the fans.
