12. Color palette

"Color palette" menu can change the fake color of the infrared
image displayed on the screen or captured. A series of color palette
is available for usage. Some color palettes are more applicable to
the special areas, so they are set as required options. Gray-scale
color palette provides balanced linear color, so it can help to fully
reveal details. High-contrast color palette can emphasize the
displayed color. This color palette is applicable to the hot-cold
contrast situation. It is used to improve the color contrast of
high-temperature and low-temperature. Iron red and rainbow color
palettes provide a mixed high-contrast gray-scale color palette.

13. Temperature of reflective background

The background temperature can be set between 0°C and +36°C.
Set the temperature compensation for reflective background in the
option of background. Over-hot or over-cold object may influence
the object or the surface temperature and measurement accuracy
of measured object. When the radiation coefficient of the surface of
the measured object is low, this phenomenon is obvious. Under
many situations, adjust the temperature of reflective background to
get the optimum measured result.

14.Marking of spot temperature

Turn on or off the marking of spot temperature. If turning on, the
marking of spot temperature indicates that the hot spot or cold spot
in the screen needs additional appraisal. If turning off, it indicates
that user can focus on the measured pixel per time.

15.Unit of temperature

The product displays the temperature in unit of °C or °F.
High contrast
Iron red
Rainbow
8

16. Image mixing

Use the aligned visible image and infrared image. The mixed image
makes the understanding of infrared image become easier. The
product can capture the visible image of each infrared image to
accurately display the temperature distribution of target area. It
helps to share with others. If this mixing function is used, press "left"
or "right" key to adjust the mixed image from 0% to 100%.
0%
30%

17. Time setting

In clock menu, use can set time and date. Press "menu" key to
enter into "menu" mode. Press "up" or "down" key to select "clock"
menu. Press "select" key to enter into the mode of clock calibration.
Press "left" or "right" key to select the aimed time parameter. Press
"up" or "down" key to add or subtract the value. After setting, press
"menu" key to exit.
Year Month Day
14
11
Hour Second
60% 80% 100%
4 26
12
9
