Please refer to radiation coefficient to get the actual temperature.
The measured temperature might be lower than the actual
temperature because of reflective surface. These surfaces might be
the potential burning hazard for user.

3. Performance indexes

Display screen
color screen
Resolution of infrared image
Resolution of visible image
Field angle/shortest focal distance
Thermal sensitivity
Range of temperature measurement
Accuracy of temperature measurement ±2% or ±2°C (±2% or ±4 )
Emissivity
Image capturing frequency
Range of wave length
Focal distance
Color palette
Vision option
Memory card
File format
Power supply
Battery life
Auto power-off time
Authentication
Dimension of product (L*W*H)
Weight
Operating temperature
Storage temperature
Relative humidity
2.4" full-angle high resolution
60*60 (3600 pixels)
0.3 mega pixels
20*20/0.5m
0.15°C
-20°C to +300°C
Adjustable 0.1-1.0
6Hz
8-14um
Fixed focal distance
Iron red, rainbow, rainbow
high contrast, gray scale
(white glow) and gray scale
(black glow)
25% step infrared to visional
to infrared and visional image
Mini SD card
bmp
AA battery * 4
6 hours
12 minutes
CE (EN61326-1:2006)
212mm*95mm*62mm
320g
-5°C to ±40°C
-20°C to ±50°C
10% RH to 80% RH
2

4. Product description

Press "tart-up" key for 5 seconds and the instrument starts up.
Press "menu" key for 1 second to enter into the mode of the setting
of basic functions. There are only five options on the display screen.
Press "up" or "down" key to scan the menu and select the yellow
option box.
Press "select" key and select "menu" option and edit the value.
Press "up" or "down" key to edit the value. After adjustment, confirm
the new value and press "menu" key to exit the edit mode.
Start-up/enter menu
Figure 1- Basic Functions
Yellow option
box
Select/input
Navigation key
(up/down/left/right)
