Specifications
Input Impedance
Max Input Level
Input connector
Output Impedance
Max Output Level
Max Gain
S/N Ratio
THD
Power Requirement
Dimension WxHxD
Weight (LBS)
100K-ohm, Unbalanced
+15dBu
Stereo 1/4"TRS Jack
80-Ohm Each
40mW in 100ohm
20dB/Channel
More than 90dB
Less than 0.03%
12V DC/150mA
4.07" x 1.18"2.24"
0.42LBS
www.PyleAudio.com
ULTRA-COMPACT MONITOR HEADPHONE AMPLIFIER
MODEL:PHA211
Advertisement
Related Manuals for Pyle PHA211
Summary of Contents for Pyle PHA211
- Page 1 Stereo 1/4"TRS Jack Output Impedance 80-Ohm Each Max Output Level 40mW in 100ohm ULTRA-COMPACT MONITOR HEADPHONE AMPLIFIER Max Gain 20dB/Channel S/N Ratio More than 90dB MODEL:PHA211 Less than 0.03% Power Requirement 12V DC/150mA Dimension WxHxD 4.07" x 1.18"2.24" Weight (LBS) 0.42LBS...
- Page 2 9. MIC OUTPUT VOLUME CONTROL 10. MONITOR OUTPUT VOLUME CONTROL PHA211 SPECIFICATION The Ultra-Compact Monitor Headphone Amplifier PHA211 is PYLE Newest Product with the Ideal Personal Monitor Mixer for the Performance. Featuring a flexible Mic In and Mic Through Connectors...
- Page 3 Supply and an LED to Indicate When it is Powered Up. MASTERFUL MONITOR MIXING WITH SMALL SIZE BUT SUPERB FUNCTION PHA211 is Capable of Either Stereo Mono Operation, and is a Powerful Little Mixer. Simply Adjust the PHA211's Monitor Level Control to a Comfortable Setting with the Microphone Level Control.
- Page 4 9.Damage Requiring Service-The appliance should be IMPORTANT SAFETY INSTRUCTIONS serviced by qualified service personnel when: A.The power supply cord or plug has been damaged. -All the safety and operating instructions Read Instructions B.Objects have fallen into, or liquid has been spilled into should be read before the appliance is operated.
