- Page 1 Instructions Instrucțiuni de utilizare - RO Anleitung - D Eredeti használati utasítás - HU Ръководство за употреба - BG Instrukcja obsługi - PL www.heinner.com VCRP001...
-
Page 2: General Safety Rules
ROTARY HAMMER Thank you for choosing Heinner! GENERAL SAFETY RULES WARNING: For your personal safety, READ and UNDERSTAND before using. SAVE THESE INSTRUCTIONS FOR FUTURE REFERENCE. WARNING: Read and understand all instructions. Failure to follow all instructions listed below may result in electric shock, fire and/or serious injury. -
Page 3: Specific Safety Rules
ROTARY HAMMER left attached to a rotating part of the power tool may result in personal injury. 13. Do not overreach. Keep proper footing and balance at all times. This enables better control of the power tool in unexpected situations. 14. - Page 4 ROTARY HAMMER 4. Wear a hard hat (safety helmet), safety glasses and/or face shield. Ordinary eye or sun glasses are NOT safety glasses. It is also highly recommended that you wear a dust mask and thickly padded gloves. 5. Be sure the bit is secured in place before operation. 6.
-
Page 5: Functional Description And Specifications
Locking sleeve Clamp screw Release button Depth gauge Mode selector switch (drill stop) Adjusting dial Mode selector switch (chisel stop) Grease cover On/Off switch Model VCRP001 TECHNICAL DATA Power supply 230V~50Hz Power input 1500W No load speed 800/min Impact rate... - Page 6 ROTARY HAMMER Intended Use The tool is intended for hammer drilling in concrete, brick and stone as well as for light chiseling work. It is also suitable for drilling without impact in wood, metal, ceramic and plastic. WARNING: MISUSE or failure to follow the safety rules stated in this instruction manual may cause serious personal injury.
- Page 7 ROTARY HAMMER Number on adjusting dial No load speed(rpm) Impact rate (bpm) 4000 3200 2400 1600 WARNING: • If the tool is operated continuously at low speeds for a long time, the motor gets overloaded, resulting in tool malfunction. • The speed adjusting dial can be turned only as far as 5 and back to 0. do not force it past 5 or 0, or the speed adjusting function may no longer work.
- Page 8 ROTARY HAMMER Drilling For drilling in wood, metal or plastic materials, depress the release button 3 and rotate the mode selector switch 4 so that the pointer points to the symbol . Rotate the mode selector switch 5 so that it points to the symbol .
- Page 9 ROTARY HAMMER Tighten Loosen Fig. 6 Depth gauge (see figure 6) The depth gauge 9 is convenient for drilling holes of uniform depth. Insert the depth gauge into the hole in the grip base. Adjust the depth gauge to the desired depth and then tighten the clamp screw 8 to secure the depth gauge.
-
Page 10: Operation
ROTARY HAMMER Dust cup Use the dust cup to prevent dust from falling over the tool and on yourself when performing overhead drilling operations. Dust cup Fig. 9 Grease feeding Caution: Prior to grease feeding, always disconnect the plug from the power supply receptacle. Since a grease chamber is built in this Rotary Hammer, it can be used for approximately 30 days without supplying lubricating grease, assuming that the hammer is used continuously 2 hours daily. -
Page 11: Maintenance
ROTARY HAMMER Chiseling operation First set the mode selector switch 4 and the mode selector switch 5 to the position shown in the figure 4. Hold the tool firmly with both hands. Turn the tool on and apply slight pressure on the tool so that the tool will not bounce around, uncontrolled. - Page 12 ROTARY HAMMER • The brushes and commutator in your tool have been engineered for many hours of dependable service. To maintain peak efficiency of the motor, we recommend every two to six months the brushes be examined. • A damaged dust cap should be changed immediately. We recommend having this carried out by an after-sales service.
- Page 13 ROTARY HAMMER Hammer drilling Wear ear defender Wear safety goggles Chiseling Drilling Wear a dust mask Double insulation Recycling EC-Declaration of conformity SDS-plus chuck Max. drilling capacity in concrete Mode Selector Switch additional content Hammer drilling: For drilling in concrete, masonry, etc. Use a tungsten-carbide tipped bit. Chiseling: For chipping, scaling or demolition operations.
- Page 14 ROTARY HAMMER RECYCLING Electrical and electronic equipment waste (WEEE) might contain dangerous materials which can have a negative impact on the environment and human health if not collected separately. This item is in conformity with the European Directive EU WEEE (2012/19/EU) and is marked with an electronic and electrical waste logo graphically represented in the image below.
