- Page 1 TERADICI PCOIP ® REMOTE WORKSTATION CARD Quick Start Guide Models: TERA2220 Dual Display TERA2240 Quad Display Actual products may not be exactly as shown.
-
Page 2: Package Contents
Teradici PCoIP Remote The package contents include: • PCI Express x1 compatible card slot (Full Height, Workstation Card. This card Half Length for TERA2240, Low Profile provides a rich computing • Teradici PCoIP Remote Workstation Card for TERA2220) experience with delivery of up to •... -
Page 3: Installation Steps
Front Panel Switch INSTALLATION STEPS Setting up the PCoIP Remote Workstation Card NOTE: The workstation card’s MAC address is located on a sticker on the card. It is important to write down this address before installing the card in the host PC. You will need it to connect to the card using SLP host Host Card discovery. - Page 4 6. Connect the workstation card to your network using the Ethernet port. Replace the chassis cover and reconnect power cables. 7. Using the appropriate cables, connect the graphics card to the Start up the host PC. workstation card. To get a desired resolution, all the components of Ensure the workstation card is installed correctly by checking that your system (workstation card, graphics card, zero client, and the heartbeat LED at the back of the card is continuously flashing red.
- Page 5 Use the rear ports if they are available. NOTE: PCoIP Software client. Client is also available for connection on-the-go from your Mac or PC. c. Connect the other end of the DVI Y-cable to the secondary monitor. Please see more details at www.teradici.com/remote-workstation...
-
Page 6: Establishing A Pcoip Connection
ESTABLISHING A PCOIP CONNECTION Some PCoIP Zero Clients are pre-configured to connect directly to a Making the Connection - SLP PCoIP Remote Workstation Card. They can also be configured to use a The steps below show how to use Service Location Protocol (SLP) to third-party connection broker, such as Leostream Connection Broker ™... - Page 7 ESTABLISHING A PCOIP CONNECTION (Continued) 3. Click Connect. Making the Connection – Direct to Host The SLP discovery process starts, and the message “Discovering hosts, please wait…” displays. When discovery completes, the IP If the PCoIP Remote Workstation Card IP address is known (see KB 15134- and MAC addresses of any discovered workstation cards are listed on 1348 for details) or its default IP address is used, you can choose Direct the screen.
- Page 8 For troubleshooting tips and instructions on using other methods of Workstation Card PCoIP Clients connecting a PCoIP client endpoint to a PCoIP Remote Workstation TERA2240 Quad Card, please refer to the appropriate documentation listed in the • TERA2140 PCoIP Zero Client RESOURCES section of this guide.
-
Page 9: Additional Software Tools
RESOURCES ADDITIONAL SOFTWARE TOOLS Teradici Support Site - help.teradici.com Teradici PCoIP Host Software Driver (recommended and are required if • workstation cards are brokered). • PCoIP® Remote Workstation Card Firmware Administrators' Features include: Guide • No mouse pointer lag on higher latency networks (over 50 ms) •... -
Page 10: Specifications
PRODUCT WARRANTY & SUPPORT This product is covered by a three (3) year warranty period from the time of purchase. You must register your card to activate the warranty and support at teradici.com/warranty For more information, visit teradici.com/remote-workstation or contact your reseller. - Page 11 © 2004-2018 Teradici Corporation. All rights reserved. Teradici, PCoIP and PC-over-IP are trademarks of Teradici Corporation and may be registered in the United States and/or other countries. All other trademarks are property of their respective owners. Specifications subject to TER1207006-4...
