SAL-20 Mark II Package Contents
SAL-20 Mark II Antenna Material List
QTY
1 Aluminum 22 ft mast kit with hardware
14 2" x 1/4"-20 bolts with safety hex nuts
3 6 ft (1.83 m) 1-1/2" (38.1 mm) OD aluminum tubing
1 4 ft (1.83 m) 1-1/2" (38.1 mm) OD aluminum tubing (double wall)
2 Tie-down "D" rings with plates for ¼" bolts
2 Insert coupling 1-3/8" x 7" (31.75 mm x 182 mm) aluminum insulator
1 Insert coupling 1-3/8" x 3-1/2" (34.9 mm x 88.9 mm) aluminum tubing
1 Insert coupling 1-1/4" x 7" (31.75 mm x 182 mm) fiberglass insulator
Solder eye lugs for 1/4" bolts (attached to cable loops)
8
44' (10.36 m) cables for loops (with TX line, coupler, and solder lug)
4
4 Anchoring Stakes
40 ft of rope to cut as follows*: 4 x 10 ft (3.05 m) guying ropes.
2 Hose clamps 2"
1 PVC Mast base with 4" pipe inserted
4 Couplers with 10 ft (3.05 m) 120 ohm TX lines (attached to the loops)
4 Guy rope tensioners
1 11 ft (3.35 m) RG-6 coaxial cable delay line with F connectors attached
1 Control Switch
1 Combiner/Pre-amp
1 15v Power supply
Suggested cutting lengths may vary depending on site's topography.
*
