PHONE (305) 625-2451, (800) 762-7565, FAX (305) 623-0475, E-mail:
PARTS LIST FOR MECHANICAL COLD PANS
WCM/WCMD/WCMDC/WCML/WCMDL & WCMDCL SERIES
8
PART NUMBER
ITEM NUMBER
1
1
2
3
4
5
6
7
7
7
8
9
10
11
12
13
14
15
16
Subsidiary of Mercury Aircraft, Inc.
1135 N.W. 159th DR., MIAMI, FL 33169
2
9
7
10
S80103-0
S85008-0
86-3202
7020-0
7002-0+Model #
2044-0
1099-0
2029-0
2029-1
2029-2
49-1028
30-3130
3016-2
7041-0
1003-0
2025
2026
2027
600008
1
12
5
6
WCM-4 SHOWN
DESCRIPTION
Separator Channel (WCM & WCMD)
Separator Channel (WCML & WCMDL)
Perforated Snap- In Drain
Vinyl Bead Gasket
1/5 H.P. Compressor
(WCM-WCMD-WCMDC-1-2-3-WCML-WCMDL-WCMDCL-2-3)
1/4 H.P. Compressor
(WCM-WCMD-WCMDC-WCMDL-WCMDCL-4)
1/3 H.P. Compressor
(WCM-WCMD-WCMDC-5-6)
3/4 " x 4" PVC Nipple
Power Cord Bushing (Not Shown)
Drier (Not Shown)
0.042 Cap Tube for 1/4, 1/3 & 1/2 Compressor (Not Shown)
0.031 Cap Tube for 1/5 Compressor only (Not Shown)
Thermostat Knob
sales@atlasfoodserv.com
4
3
Nylon Spacer
Thermostat
Pilot Light
Grommet
Stop Valve
Power Cord
Advertisement
Table of Contents
Related Manuals for Atlas Metal WCMD SERIES
Summary of Contents for Atlas Metal WCMD SERIES
- Page 1 Subsidiary of Mercury Aircraft, Inc. 1135 N.W. 159th DR., MIAMI, FL 33169 PHONE (305) 625-2451, (800) 762-7565, FAX (305) 623-0475, E-mail: sales@atlasfoodserv.com PARTS LIST FOR MECHANICAL COLD PANS WCM/WCMD/WCMDC/WCML/WCMDL & WCMDCL SERIES WCM-4 SHOWN PART NUMBER DESCRIPTION ITEM NUMBER S80103-0 Separator Channel (WCM &...
- Page 2 MECHANICAL COLD PANS WCM/WCMD/WCMDC/WCML/WCMDL & WCMDCL SERIES ----------------------------------------------------------------------------------------------------------------------------------------------------------------------- INSTALLATION Provide the correct counter cut-out opening (see chart below) and drop in. The vinyl gasket assures complete seating. A non-toxic silicone seal may be used between the gasket and counter top (not required). Note: Units are supplied with a nipple and stop valve to be connected for draining.
