Summary of Contents for National Flooring Equipment 5274
- Page 1 5274 FLOOR PREPARATION SYSTEM OPERATING MANUAL Read Manual Before Operating Machine 402595 Rev C...
-
Page 3: Table Of Contents
Table of Contents Table of Contents ................................3 Features and Specifications ............................4 Safety ....................................5 General Rules for Safe Operation ......................... 5 Grinder Safety Guidelines ............................6 Components and Assembly ............................7 Loading and Unloading ............................7 Plate Attachment and Removal ..........................7 Rubber Dust Guard .............................. -
Page 4: Features And Specifications
Features and Specifications Handle power cord 1.5 HP Motor Floating Deck Head Adjustable Rubber Removable Cutting Head Dust Guard 16” Cutting Head FEATURES Floating Deck Head- Allows the cutting head to follow the countour of Adjustable Rubber Dust Guard - Provides a dustless operation. the surface, providing uniform operation in low spots. -
Page 5: Safety
Read the manual carefully to learn equipment applications and limitations, as well as potential hazards associated with this type of equipment. Keep manual near machine at all times. If your manual is lost or damaged, contact National Flooring Equipment (NFE) for a replacement. Personal Maintenance &... -
Page 6: Grinder Safety Guidelines
Safety Safety GRINDER SAFETY GUIDELINES Before use, anyone operating this equipment must read and understand these safety instructions. Grinding Dust Collection Beware of hidden obtrusions. Use with appropriate dust collecting system. Watch out for hidden dangers and protrusions in flooring. Do not Do not operate machine designed for use with a dust collector use on largely uneven surfaces. -
Page 7: Components And Assembly
Components and Assembly LOADING AND UNLOADING • Always disconnect from power source before transporting. • Disconnect the handle cord from the motor plug cord in order to remove the handle and make the machine more compact. PLATE ATTACHMENT AND REMOVAL Many plate choices are available for the following uses: scraping, grinding, sanding, FIG. -
Page 8: Vacuum Port
Components and Assembly If rubber guard securing Velcro becomes loaded up with debris, wash out with mild soap or blow out with an air hose. If Velcro on the machine is damaged or worn out, replace before using the machine. If the rubber guard is cut, damaged or worn out, replace before using the machine. -
Page 9: Operation
Operation START-UP PROCEDURE Machine must be off before plugging into power source. Power Cord Plug the motor cord into the handle cord plug, if not connected (Figure 6). Plug cord into proper size extension cord. Plug extension cord into outlet. Handle Cord Depress handle to relieve pressure from the plate to the floor. -
Page 10: Troubleshooting Guide
Troubleshooting Guide Problem Solution Machine is hard to handle Change to a less aggressive tooling. Allow wheels of machine to engage the floor to create drag. Machine is overloaded Let machine rest and cool down. Less aggressive tooling. Ensure use of proper extension cord. See Safety section. Debris is coming out from the bottom of the Check rubber guard to make sure it is mounted and secured properly. -
Page 11: Warranty
Warranty National Flooring Equipment Inc. (referred to as “The Company”) warrants that each new unit manufactured by The Company to be free from defects in materials and workmanship in normal use and service for a period of twelve (12) months from date of shipment from The Company to the end user. - Page 12 9250 Xylon Avenue N • Minneapolis, MN 55445 • U.S.A. Toll-free 800-245-0267 • Phone 763-315-5300 • Fax 800-648-7124 • Fax 763-535-8255 Web Site: www.nationalequipment.com • E-Mail: info@nationalequipment.com...
