Illustra Flex 2MP Indoor and Outdoor IR PTZ Dome Quick Start Guide
Illustra Flex Series 2MP Indoor and Outdoor IR
This chapter provides product features, installation procedures, and connection information regarding
the Illustra Flex Series 2MP Indoor and Outdoor IR PTZ cameras.
Product features
Lens cases require special care when handling and cleaning to avoid scratches. For information on
camera head handling and cleaning, see 8200-1174-01 Bubble Clearing Procedure Application Note.
Go to https://illustracameras.com/products.
From the Products page, select your camera product range and then select your camera model. Click
Downloads and search for Bubble Handling and Cleaning Procedure.
Product overview
This chapter explains the features and installation of the Flex IR PTZ cameras. Product code and
description of the camera is provided in the table below.
Table 1 Product code and description of the Flex IR PTZ camera
Product Code
IFS02P6INWIT
IFS02P6ONWIT
Figure 2 Physical dimensions of the Flex IR PTZ cameras (mm)
8200-1456-10 B0
PTZ Camera
Illustra Flex 2MP IR PTZ camera, 30x, indoor, vandal, white, TDN, TWDR
Illustra Flex 2MP IR PTZ camera, 30x, outdoor, vandal, white, TDN, TWDR
Description
5
