  • Page 1 Getting Started Guide for the Regalia ™ Model BLPS4-RG...
  • Page 2: Table Of Contents

    Table of Contents Pages Important Safety Instructions ................3 Installation Instructions ..................7 Congratulations on your Pro-Stitcher purchase ..................7 Parts List ..............................8 Installation ............................... 11 Installation of the X-Rack and Y-Rack ...................... 11 To set up the Pro-Stitcher carriage ......................14 To attach the tablet computer .........................
  • Page 3: Important Safety Instructions

    This machine is intended for household or commercial use. Disclaimer Baby Lock and its Representatives are in no way legally responsible or liable for damage to the Pro-Stitcher when used improperly or not in accordance with the guidelines stated in this manual or when used on machine quilting frames not recommended by Baby Lock.
  • Page 4 Read these instructions before using the machine. To use the machine safely 1. Keep hands and loose clothing away from wheels, gears or other moving parts. 2. Turn the machine off and unplug the cord in the following cases: • When you have stopped using the machine •...
  • Page 5 Cette machine est destinée à un usage domestique. Avertissement Baby Lock et ses représentants ne sont en aucun cas juridiquement responsables des dommages causés à Pro-Stitcher lorsque cellle-ci est utilisée de manière inadéquate ou non conforme aux consignes énoncées dans ce manuel ou lorsqu'elle est utilisée sur des cadres de machine à quilter non recommandés par Baby Lock.
  • Page 6 Lisez ces consignes avant d'utiliser la machine. Pour utiliser la machine en toute sécurité 1. N'approchez pas les mains et les vêtements amples des roues, des engrenages ou des autres pièces mobiles. 2. Mettez la machine hors tension et débranchez le cordon dans les cas suivants : •...
  • Page 7: Installation Instructions

    If you do not pack the machine properly or if you do not use the correct packaging materials, the machine could be damaged. Baby Lock is not liable for damage that occurs during return shipping.
  • Page 8: Parts List

    Optional U.S. Grounding GROUNDED OUTLET BOXES TAB FOR METAL GROUNDING SCREW SCREW GROUNDING PIN ADAPTER This product is for use on a nominal 120 V or nominal 220 V circuit, and has a grounding plug that looks like the plug illustrated in sketch A above. A temporary adapter, which looks like the adapter illustrated in sketches B and C, may be used to connect this plug to a 2-pole receptacle as shown in sketch B if a properly grounded outlet is not available.
  • Page 9: Pro-Stitcher

    D. 3/32-inch drill bit E. Pro-Stitcher Carriage F. Computer bracket with black box and hinge G. Y-axis mounting bracket assembly H. Y bracket screws and washers (10-24 x 1/2") 2 each I. Power cord assembly I-1. 10-foot power cord (from power filter output) I-2.
  • Page 10: Pro-Stitcher

    M. Pro-Stitcher communication cable (from machine back panel to Pro-Stitcher carriage) N. Black Box power cable (from board under front face cover plate to bottom of black box) O. USB cable (top of black box to tablet) P. Computer power cord (black box to tablet, ferrite to black box) Q.
  • Page 11: Installation

    Installation These instructions are for installing Pro-Stitcher on your Baby Lock machine (with an 8-wheel Precision- Glide™ carriage). Baby Lock recommends installation by an authorized Pro-Stitcher retailer, if available.  NOTE: This installation is easier to complete without the frame side arms or poles in place. If the side arms have already been installed, it is not necessary to remove them, but the poles should be removed.
  • Page 12 3. Use the carriage as a guide and align the blue Flexirack with the white gear along the length of the table (see arrow at right), removing the pink protective layer and pressing downward on the blue Flexirack while moving the carriage down the entire length of the table.
  • Page 13  NOTE: As an alternative, use one clamp at each end. Slide the lip of the clamp over the last gear of the blue Flexirack, drill a pilot hole, and screw in place. To Install the Y-Rack 1. Carefully lay the quilting machine on its left side (looking from the front). Pay close attention to the Y-encoder mounted to the rear left wheel so you do not damage the Y-encoder bracket.
  • Page 14: To Set Up The Pro-Stitcher Carriage

    To set up the Pro-Stitcher carriage U CAUTION: Before plugging any cables into the carriage or the tablet computer, be sure the quilting machine power cord is unplugged from the wall so there is no power to the quilting machine or Pro-Stitcher carriage.
  • Page 15: Pro-Stitcher

    6. Place the ends of the power cord-retaining clamp (see Parts List, item T) into the holes on the retainer screws on the back connection panel. The u-shape should be aiming down so it can go down over the plug to retain the cord inside the machine connector.
  • Page 16: Pro-Stitcher

    9. Verify that the Y-axis gear engages the blue Flexirack on the Y-axis bracket. • Do this by looking from the back of the machine between the bottom of the quilting machine and the top of the carriage. If necessary, use the manual engagement/disengagement tool to move the gears so they engage.
  • Page 17: To Attach The Tablet Computer

    To attach the tablet computer  NOTE: Steps 1 and 2 are only required if the 7” display is attached to the quilting machine 1. Remove the front display USB cable from the bottom of the display. 2. Using a Phillips head screwdriver, remove the four small front-hinge screws from the front display bracket.
  • Page 18: Installing The Front Power Cable

    2. Install the black box power cable (see parts list, item N) into the front face cover circuit board to power the black box on the tablet mount. 3. A. Plug the front power cable firmly into the front circuit board at the location marked J4 on the circuit board.
  • Page 19: Connecting The Computer Tablet

    Connecting the computer tablet 1. Looking from the back of the computer tablet, with the computer installed in the bracket, connect the USB cable (see Parts List, item O) between the USB port, on the top-left side of the computer (position A) and black box on the back of the bracket to the top-right side of the black box (position D).
  • Page 20: To Turn On And Shut Down Pro-Stitcher

    To turn on and shut down Pro-Stitcher To turn on Pro-Stitcher • Turn on the quilting machine first (the Pro-Stitcher computer will try to communicate with the quilting machine when it boots up and will not be able to do so if the quilting machine is off). •...
  • Page 21: Troubleshooting

    Troubleshooting Problem/Symptom Corrective Measure The Pro-Stitcher tablet computer screen is black (no power) The Pro-Stitcher computer is powered off. Press the Power button on the monitor to turn it on (you may have to hold the button for several seconds on some computer tablets).
  • Page 22 Problem/Symptom Corrective Measure The stitch regulator cable is not connected properly (continued) The Pro-Stitcher moves but does not stitch. Check that all cables are securely attached. Verify the Pro-Stitcher and the quilting machine are communicating with each other. Choose the Settings tab, then the Advanced button.
  • Page 23 Problem/Symptom Corrective Measure The X and Y tension springs are too loose. Gear tooth skipping occurs, causing the The X and Y tension springs may need to be tightened. stitched design to be shifted in either the X or First make sure the Pro-Stitcher version is 14.01.0043 the Y direction.
  • Page 24 USB flash drive, wait about 15 seconds, and then press the Open button again. The patterns that come pre-loaded on the Baby Lock USB Flash drive are located in a folder called Designs on the USB flash drive (usually drive D:\ or E:\). From the Open window, select a drive letter by pressing on the arrow button next to the drive you wish to browse.
  • Page 25 Problem/Symptom Corrective Measure Error messages Motor Error with lightning bolt icon in the top- This will occur with various types of motor errors. right corner (may occur with various types of Generally they mean that the Pro-Stitcher cannot Motor Error messages on the screen). communicate with the motors.
