F&eIT Series AC Power Adaptor
POA200-20 User's Guide
This product is AC-DC power adaptor to supply 5VDC power supply to the F&eIT series.
Dimensions
105±1
Connector
MC1,5/3-ST-3,5 [made by Phoenix Contact Corp.]
Specifications
Item
Input voltage range
Rating input current
Rating output voltage
Rating output current
Operating requirements
holding time
Service life
1
CONTEC CO.,LTD.
1500±50
90 - 264VAC
0.3A (Max.)
5VDC±5%
2.0A (Max.)
0 - 40°C, 20 - 80%RH (No condensation)
16ms (Typ.) (AC IN 100V, Io=100%)
16ms (Typ.) (AC IN 200V, Io=100%)
It is three years (Io=100%) at the circumference temperature of 25°C
It is one year (Io=100%) at the circumference temperature of 40°C
1500±50
[mm]
Specifications
+5V
GND
N.C.
POA200-20
