Caution: Disconnect the micro USB power connection and place the power switch on
the right side of the unit in the OFF position before beginning the replacement.
TREK Micro Battery Replacement Instructions
1. Using a 1.5 mm. hex wrench, remove the four
screws holding the bottom plate.
2. With a tweezers or needle nosed pliers,
carefully lift the bottom plate.
3. Lift the cable and connector.
Advertisement
Related Manuals for TDK TREK Micro
Summary of Contents for TDK TREK Micro
- Page 1 TREK Micro Battery Replacement Instructions Caution: Disconnect the micro USB power connection and place the power switch on the right side of the unit in the OFF position before beginning the replacement. 1. Using a 1.5 mm. hex wrench, remove the four screws holding the bottom plate.
- Page 2 4. With a small screw driver or other tool, lift the battery assembly. 5. Unplug the connector. 6. Remove the old battery and insert the replacement. 7. Plug in the connector and press the cable in place.
- Page 3 8. Reinstall the four retaining screws. Proper disposal of the old battery is essential from an environmental and safety point of view. Please follow local regulations for proper disposal. Putting any battery directly in the trash will harm the environment. Do not incinerate.
