INSTALLATION
SINGLE PACKAGE
AIR CONDITIONERS
MANUAL
ELECTRIC/ELECTRIC,
AIR-COOLED
TABLE OF CONTENTS
DAPM024 THRU 060
GENERAL . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
2 THRU 5 TON (13 SEER)
INSPECTION. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
REPLACEMENT PARTS . . . . . . . . . . . . . . . . . . . . . . . . 3
INSTALLATION . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
MAINTENANCE . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
TROUBLESHOOTING . . . . . . . . . . . . . . . . . . . . . . . . . 16
