Summary of Contents for ClimateRight easyair CR12000SACH

Page 1 easyair OWNER’S MANUAL & INSTALLATION GUIDE Do it y urself Install without the need for an HVAC technician Mini Split - Single Zone Air Conditioner and Heat Pump Model: CR12000SACH IMPORTANT: READ CAREFULLY BEFORE ASSEMBLY AND USE Read and follow all safety rules and instructions before operating this equipment. THIS PRODUCT IS INTENDED FOR HOUSEHOLD USE ONLY.
Page 2: Table Of Contents
4 Speeds High | Medium | Low | Auto Duct System Through-wall with 2.75” diameter INTRODUCTION hole Thank you for choosing ClimateRight. This owner’s manual Mount Interior: Wall Mount will provide you with valuable information necessary for the Exterior: Level Surface proper care, installation, and maintenance of your new product.
Page 3: Safety Instructions
WARNING: TO REDUCE THE RISK SAFETY INSTRUCTIONS IMPORTANT SAFETY INSTRUCTIONS FOR USING YOUR OF FIRE, ELECTRIC SHOCK OR INJURY: Mini Split Air Conditioner and Heater • Fully assemble before operating. This symbol indicates that ignoring instructions may • Do not repair or modify the unit. All repairs should be cause death or serious injury.
Page 4: Product Description
PRODUCT DESCRIPTION Indoor Unit Wall Mount Bracket Indoor Unit, Clip on exterior Evaporator hole cover Adjustable Fan Vent Drain Line HOW IT WORKS This air conditioner is designed to create Electrical Wiring a comfortable climate for individuals in the Refrigerant Line affected room.
Page 5: Indoor Unit Digital Display
INDOOR UNIT DIGITAL DISPLAY POWER ICON: Green: Indicates unit is on Red: Indicates unit is off TEMPERATURE AND ERROR CODE DISPLAY: Solid number: temperature reading of indoor environment Blinking number: Display blinks when you set the desired temperature. Once desired temp is set the display will go back to current indoor environment temperature and begin moving towards the desired temp.
Page 6: Remote Diagram
REMOTE CONTROLLER BUTTON DIAGRAM Indicates the selected air rate. (It works on three dimensional air flow model.) LAMP button Turns off digital display on indoor unit.
Page 7: Pre Set-Up Instructions
• Make sure there are enough screws in the mount to support noise. the weight of the unit. • Contact ClimateRight® Customer Service if you hear irregular • If the wall is made of brick, concrete, or similar material, drill sounds during operation.
Page 8 INSTALLATION OF INDOOR UNIT TOOLS YOU WILL NEED WARNING: - Stud Finder - Step Ladder Read all safety instructions on page 3 before installing indoor unit. - Pencil - Level Read all indoor installation requirements. It is recommended that - Drill with Drill Bits - 2-3/4 hole saw two people be used for the following installation steps.
Page 9 Drill hole for line set. Using a 2-3/4" hole saw, drill a hole through the wall to feed the refrigerant lines, electrical wire and drain hose to the outdoor unit. Refer to figure 3 for recommended hole placement. It is important to drill the hole at a slight downward angle from inside to outside to ensure proper drainage of indoor unit (figure 4).
Page 10 INSTALLATION IF THE UNIT IS SURROUNDED ON THREE SIDES: Make sure each side of the unit has 12 in clearance and at least OF OUTDOOR UNIT 8 in of clearance from wall. Make sure the fan at the front is not blocked.
Page 11 INSTALLING OUTDOOR UNIT WARNING: Read all safety instructions on page 3 before installing outdoor unit. Read all outdoor installation requirements. DO NOT: • DO NOT install near an obstacle that will block air inlets and outlets. • DO NOT install near a public street, crowded areas, or where noise from the unit will disturb others. •...
Page 12: Wiring Outdoor Unit
WARNING: BEFORE PERFORMING ELECTRICAL WORK, READ THESE REGULATIONS All wiring must comply with local and national electrical codes, and must be installed by a licensed electrician. All electrical connections must be made according to the Electrical Connection Diagram located on the panels of the indoor and outdoor units. If there is a serious safety issue with the power supply, stop working immediately.
Page 13 WARNING: REDUCE RISK OF SHOCK Read all safety instructions on page 3 and page 12 before wiring outdoor unit. DO NOT plug in the power cord to an outlet while working on wiring. CONNECTING POWER CORDS 11. On the outdoor unit, remove the screw that holds the side panel. Feed utility power cord with the blue spades and line set power cord through the holes in the bottom of the access panel.
Page 14: Maintenance
7. When dry, re-clip the air filter to the larger filter, then slide it outdoor ambient protection WARNING: back into the indoor unit. If any of these errors arise please contact ClimateRight service 8. Close the front panel of the indoor unit. team immediately at (800) 725-4628.
Page 15 These indicate errors in the unit. Identify the error code from the table on page 14 where the temperature is usually and contact ClimateRight service team at (800) displayed 725-4628. Do not attempt to fix yourself. Not large enough breaker to handle operation of unit.
Page 16: Warranty
DIY series units. (Always check www.climateright.com/featured/product-registration-and- your local laws.) warranty to submit your claim as well. If ClimateRight LLC, at its sole discretion, deems your Warranty claim valid, a prepaid • Warranty applies only to products remaining in their original shipping label will be sent to the address provided for return of installation location.
Page 17 Mail this registration to: PRODUCT REGISTRATION ClimateRight Warranty Registration 777 Manor Park Drive Columbus, OH 43228 First Name__________________ Last Name_____________ Phone Number with Area Code_______________________ Address___________________________________________ ___________________________________________ Country____________________________________________ Model No._________________________________________ Serial No.__________________________________________ Date of Purchase___________________________________ Date of Installation__________________________________ Owners Name______________________________________...
