Zenith Z52SZ80 Service Manual page 32

LOCA. NO PART NO
R868 0RD2001F609 2K OHM 1/6 W 5%
10K OHM 1/2 W 5.00%
R891 0RD1002H609
R894 0RD1001F609 1K OHM 1/6 W 5%
0RN2201F409 2.2K OHM 1/6 W 1.00%
R895
R896 0RN8201F409 8.2K OHM 1/6 W 1.00%
R897 0RD1001F609 1K OHM 1/6 W 5%
R899 0RKZVTA001B 4.7M OHM 1/2 W 5%
SWITCH
SW01 140-275E SWITCH,PUSH SPBS222EP011
SWITCH,TACT 2LEAD 160G(TA)
SW1 140-313B
SW100 140-313A SWITCH,TACT 2LEAD 100G(TA)
140-313B SWITCH,TACT 2LEAD 160G(TA)
SW2
SW3 140-313B SWITCH,TACT 2LEAD 160G(TA)
SW4 140-313B SWITCH,TACT 2LEAD 160G(TA)
SW5 140-313B SWITCH,TACT 2LEAD 160G(TA)
SW6 140-313B SWITCH,TACT 2LEAD 160G(TA)
SWITCH,TACT 2LEAD 160G(TA)
SW7 140-313B
FILTER & CRYSTAL
FB801 125-022K FILTER,EMC 62MM 1UH
125-123A FILTER,EMC FERRITE BFD3565R2F
FB831
FB841 125-123A FILTER,EMC FERRITE BFD3565R2F
FB871 125-123A FILTER,EMC FERRITE BFD3565R2F
FB881 125-123A FILTER,EMC FERRITE BFD3565R2F
FB892 125-123A FILTER,EMC FERRITE BFD3565R2F
FILTER,EMC MLB-201209-0120P-N2 5A
L1100 0LCML00003B
L1103 0LCML00003B FILTER,EMC MLB-201209-0120P-N2 5A
0LCML00003B FILTER,EMC MLB-201209-0120P-N2 5A
L405
L406 0LCML00003B FILTER,EMC MLB-201209-0120P-N2 5A
0LCML00003B FILTER,EMC MLB-201209-0120P-N2 5A
L505
L602 0LCML00003B FILTER,EMC MLB-201209-0120P-N2 5A
L603 0LCML00003B FILTER,EMC MLB-201209-0120P-N2 5A
L604 0LCML00003B FILTER,EMC MLB-201209-0120P-N2 5A
L605 0LCML00003B FILTER,EMC MLB-201209-0120P-N2 5A
FILTER,EMC MLB-201209-0120P-N2 5A
L606 0LCML00003B
L607 0LCML00003B FILTER,EMC MLB-201209-0120P-N2 5A
0LCML00004A FILTER,EMC MLB-160808-0068L-N2 1A
L700
L702 0LCML00004A FILTER,EMC MLB-160808-0068L-N2 1A
L705 0LCML00003B FILTER,EMC MLB-201209-0120P-N2 5A
L800 0LCML00004A FILTER,EMC MLB-160808-0068L-N2 1A
L801 6200JB8012T FILTER,EMC SQE2828 17.2MH
L802 6200JB8012T FILTER,EMC SQE2828 17.2MH
L803 6200J000066 FILTER,EMC SQE3535 25MH
FILTER,EMC MLB-201209-0120P-N2 5A
L901 0LCML00003B
L902 0LCML00004A FILTER,EMC MLB-160808-0068L-N2 1A
0LCML00003B FILTER,EMC MLB-201209-0120P-N2 5A
L906
L908 0LCML00004A FILTER,EMC MLB-160808-0068L-N2 1A
L909 0LCML00003B FILTER,EMC MLB-201209-0120P-N2 5A
L910 0LCML00003B FILTER,EMC MLB-201209-0120P-N2 5A
L911 0LCML00003B FILTER,EMC MLB-201209-0120P-N2 5A
REPLACEMENT PARTS LIST
DESCRIPTION
- 32 -
LOCA. NO PART NO
L912 0LCML00003B FILTER,EMC MLB-201209-0120P-N2 5A
FILTER,EMC MLB-201209-0120P-N2 5A
L913 0LCML00003B
T400 6200QJ3001A FILTER,EMC BMS400 25V 200MA
6200VJT006A FILTER,EMC STC222D 50VOLT 4A 2200PF
T400
T401 6200QJ3001A FILTER,EMC BMS400 25V 200MA
T401 6200VJT006A FILTER,EMC STC222D 50VOLT 4A 2200PF
T402 6200QJ3001A FILTER,EMC BMS400 25V 200MA
T402 6200VJT006A FILTER,EMC STC222D 50VOLT 4A 2200PF
FILTER,EMC STC222D 50VOLT 4A 2200PF
T403 6200VJT006A
T404 6200VJT006A FILTER,EMC STC222D 50VOLT 4A 2200PF
FILTER,EMC STC222D 50VOLT 4A 2200PF
T408 6200VJT006A
T409 6200VJT006A FILTER,EMC STC222D 50VOLT 4A 2200PF
6200VJT006A FILTER,EMC STC222D 50VOLT 4A 2200PF
T410
T411 6200VJT006A FILTER,EMC STC222D 50VOLT 4A 2200PF
T414 6200QJ3001A FILTER,EMC BMS400 25V 200MA
T415 6200QJ3001A FILTER,EMC BMS400 25V 200MA
T416 6200QJ3001A FILTER,EMC BMS400 25V 200MA
FILTER,EMC BMS400 25V 200MA
T417 6200QJ3001A
T418 6200QJ3001A FILTER,EMC BMS400 25V 200MA
6200VJT006A FILTER,EMC STC222D 50VOLT 4A 2200PF
T512
T513 6200VJT006A FILTER,EMC STC222D 50VOLT 4A 2200PF
6200VJT006A FILTER,EMC STC222D 50VOLT 4A 2200PF
T514
T515 6200VJT006A FILTER,EMC STC222D 50VOLT 4A 2200PF
X1 156-A01P RESONATOR,CRYSTAL HC49U 8.000MHZ
X100 6212AB2861A RESONATOR,CRYSTAL HC-49/SM 10.00000MHZ
X1202 6212AA2009A RESONATOR,CRYSTAL HC-49U 4.00000MHZ
X1203 6212BA2002C RESONATOR,CERAMIC CSALA2M69G4ZF01-B0
X300 6212AB2860A RESONATOR,CRYSTAL HC-49/SM 20.25000MHZ
6212AA2010A
X600 RESONATOR,CRYSTAL HC-49U 18.43200MHZ
X602 6212AB2845A RESONATOR,CRYSTAL ABLS-27.000MHZ
X800 6212AB2862A
RESONATOR,CRYSTAL HC-49/SM 24.57600MHZ
MISCELLANEOUS
C20 6851V00018H CABLE,DVI-D TO DVI-D UL20276 AWG30 500MM
C21 6634VDN002K ADAPTER,RF UMX-NT-024 75 OHM
C22 6851V00022D CABLE,COAXIAL(250MM),UL1365#26 VW-1
F800 0FS5001B51D FUSE,SLOW BLOW 5000MA 250V
6927V0161AA
IC1 SOFT WARE,2.00V 6109 MD PJT NB05ED
IC101 6927V0162AA SOFT WARE,2.00V E3D4 MD PJT NB05ED
IC102 6927V0163AA
SOFT WARE,2.00V 2879 MD PJT NB05ED
IC312 6204B62702A OSCILLATOR,27.00000MHZ +/- 100 PPM
IC704 6204B47985C OSCILLATOR,SCO-103 100MHZ
PA1 6726VH0001A REMOTE CONTROLLER RECEIVER,38KHZ
TH801 163-048D THERMISTOR,NTC KL15L2R5 +/- 15%
TH802 163-048D THERMISTOR,NTC KL15L2R5 +/- 15%
TU104 6700NFNS04H TUNER,TDVL-H702P
6102W5V016A
VA600 VARISTOR,AVRL161A1R1NT
VA601 6102W5V016A VARISTOR,AVRL161A1R1NT
VA602 6102W5V016A
VARISTOR,AVRL161A1R1NT
VA603 6102W5V016A VARISTOR,AVRL161A1R1NT
VA604 6102W5V016A VARISTOR,AVRL161A1R1NT
DESCRIPTION
