Cycle Cabana
5'x10'x8'
Assembly Manual
Due to continuing improvements, actual product may differ slightly from the product described herein.
105 Woodmont Road, Milford CT, 06460
Visit our Web Site at www.mdmshelters.com
Copyright 2009 by MDM Products. All rights reserved. No portion of this manual or any artwork contained herein may be
reproduced in any way shape or form without the express written consent of MDM Products.
Advertisement
Related Manuals for Rhino Shelter CycleCabana
Summary of Contents for Rhino Shelter CycleCabana
- Page 1 Cycle Cabana 5’x10’x8’ Assembly Manual Due to continuing improvements, actual product may differ slightly from the product described herein. 105 Woodmont Road, Milford CT, 06460 Visit our Web Site at www.mdmshelters.com Copyright 2009 by MDM Products. All rights reserved. No portion of this manual or any artwork contained herein may be reproduced in any way shape or form without the express written consent of MDM Products.
-
Page 2: Safety Warning
All claims for freight damage must be made Congratulations on your purchase of a House Style with 15 days of receipt of the goods in accordance with Instant Shelter (CycleCabana ) by MDM Products LLC. ICC regulations. With proper installation, use, and maintenance, your new... - Page 3 Assembly Instructions 5x10x8 CycleCabana ITEM # DESCRIPTION QUANTITY PART # BENT SIDE CREST TUBE TOP CREST TUBE END ARCH UPRIGHT WITH FOOT CENTER STRAIGHT UPRIGHTS CROSS RAIL A CROSS RAIL B CONNER WIND BRACE A CONNER WIND BRACE B CBN-3005-3 3/8"X3-1/4"...
-
Page 4: Site Preparation
Assembly Instructions 5x10x8 CycleCabana Note: All Side and Base Ridge Poles MUST be on the inside of the Arch Frame Members. Top Ridge Poles MUST be on the outside of the Arch Frame members, except at the Ends. See Frame Assembly Step 5. -
Page 5: Frame Assembly
Assembly Instructions 5x10x8 CycleCabana Swedged end of the Cross Rails should face the interior of Part #5 Top the unit to accept the next Cross Rail. The Cross Rails Ridge Rail should be put into the bottom and side hole of the arch upright. - Page 6 Assembly Instructions 5x10x8 CycleCabana Figure 4 Finished Frame Anchoring Frame To Ground Anchor placement should be made inside the frame at the interior corners of the unit, and midway along the sides of the frames. Anchors secure the building to the ground, as Once frame is square and properly supported, tighten well as prevent spread of the frame over time.
- Page 7 Assembly Instructions 5x10x8 CycleCabana ANCHOR STEP 3 Pre-Drill Holes if there are any rocks in ground Slip one side of the U-bolt through the eyelet at the end of the anchor cable. Attach the cable to the Arch leg upright with the U-bolt and tighten.
- Page 8 Assembly Instructions 5x10x8 CycleCabana secured in position so it does not move as end doors and main cover are tightened over frame. This step is key to good fit and to pre vent door movement in wind. T he rope channels should be located inside the unit, with the frame members passing through the pre-cut slits i n the end panel/door.
- Page 9 The fabric backed PE fabric of Rhino Shelter units does not stretch. If you pull it so tight that the fabric is stretched, a small amount of additional stress from wind or contact can cause premature tears and material failure.
- Page 10 Assembly Instructions 5x10x8 CycleCabana Door Hold Ups Step4 When the cover is completely aligned secure the cover to the bottom tie-down cross rail using the rope provided. All MDM Products doors are manufactured with a pocket on the bottom edge along the width axis. A ½” to 1” plastic or S tart at one end and tie off the rope to the cross rail.
-
Page 11: Maintenance And Care
Assembly Instructions 5x10x8 CycleCabana Maintenance and Care Customer Service or Installation Assistance Annually or more often , the unit should be completely Please call MDM Products at 800-447-7079 or 203-877- 7070 for questions about the installation of the unit in any inspected internally and externally to make certain the way.
