ASSEMBLY INSTRUCTIONS
SHED STYLE 12Wx12Lx8H
Congratulations!
Congratulations on your purchase of a Shed Style
Instant Shelter by MDM Products LLC. With proper
installation, use, and maintenance, your new unit will
provide many years of good and suitable service. Your
new Rhino Shelter portable enclosure is a combination
of excellent engineering and well thought out design.
The unit is comprised of a rigid tubular frame, covered
with a long life polyethylene cover and double access
ends.
The multiple part tubular frame assembly is pre-drilled
for easy insertion of hardware to assemble. The tubing
is made from high-grade galvanized steel tubing, to
resist moisture and oxidation over the life of the shelter.
The fabric components are made from ASTM-5
approved polyethylene materials. The cover is also UV
protected for continual exposure to the sunlight.
It is suggested that you read the assembly instructions
completely before you begin. This will help attain the
best results for your installation the first time.
SAFETY WARNING
The installation of this unit must conform to the
requirements of all authorities having jurisdiction in
your specific local area. In the absence of such
requirements, the installation must conform to the
provided assembly and installation instructions.
MDM Products LLC will not be responsible for failure
to comply with any requirements in a given local
area. Consequential damages or injuries caused by
improper installation, alteration, or improper use are
strictly that of the user. Unit MUST be cleared of All
Snow Accumulation immediately to avoid overload.
Unit is not to be used for occupancy for any length
of time. No running internal combustion engines,
open flames, or contact with heated surfaces are
allowed.
Cartons should be inspected upon delivery from
carrier, and any evident damages should be noted on
the bill of lading before signing. If upon opening the
cartons hidden damage is noted, contact carrier or its
agent immediately. Claims for shipping damage MUST
be made with the shipping company. An inspection of
the goods will most likely be required. Do not discard
V2.2
Assembly Instructions Shed House Style 12 x 12 x 8
packing or any components before the freight company's
inspection. All claims for freight damage must be made
with 15 days of receipt of the goods in accordance with
ICC regulations.
ASSEMBLY PROCEDURE
The proper sequence and steps to install this unit will
produce a proper and good installation. Failure to read
and follow these guidelines may result in an improper
installation and will void all warranty and protection the
owner is entitled to with the product. The steps to be
undertaken are:
1. Perform an inventory check before beginning to be
certain all components are available for installation.
2. Prepare location and place both unit boxes near
location sight.
3. Assemble four (4) arches of unit
4. Assemble unit end arch, first interior arch, and wind
braces with first top ridge, base cross rail, and side
cross rail sections.
5. Add additional arch assemblies with each section of
top ridge rail, base cross rails and side cross rails.
6. Place frame into desired position and level frame
both end-to-end and side-to-side. Measure interior
of frame feet across opposite corners and square as
needed.
7. Anchor frame assembly to ground with provided
anchors, u-bolts and drive rod provided.
8. Install two(2) doors on both ends of frame assembly.
9. Install main cover over frame assembly.
TOOLS REQUIRED
The following hand tools are suggested for proper
installation of your new Rhino Shelter unit:
INVENTORY CHECK
Start installation procedure by removing all components
from packaging and ensure all components are present
Qty Part Number
1 MUC-8000
1 DZD-5002
1 DZD-5003
9/16" Open End Wrench
9/16" Socket or Box Wrench
Large Flat Tip Screwdriver
Maul or Sledgehammer
2-foot Level
6-Foot Step Ladder
Description
Main Unit Cover
End Panel Door with Zippers
End Panel with Zippered
Manway Door
