ELECTRONIC TEMPERATURE CONTROL WITH DISPLAY

NOTE: When the unit leaves the factory the electronic thermostat is pre-set to the
following parameters:
Temperature Scale:
Setpoint:
Differential:
NOTE: To ensure the correct operation of your unit these parameters must be adhered to.
1. Push and immediately release the SET key: the display will show the set point value.
2. Push and immediately release the SET key or wait for five (5) seconds to display the probe value again.
1. Push the SET key for more than two (2) seconds to change the set point value.
2. The value of the set point will be displayed and the * LED starts blinking.
3. To change the Set value push the
4. To lock the new set point value push the SET key again and wait 15 seconds.
5
F (Fahrenheit)
29° F
3° F
ADJUSTING ELECTRONIC THERMOSTAT
HOW TO SEE THE SETPOINT
HOW TO CHANGE THE SETPOINT
(up) or (down) arrows.
