- Page 1 REMOTE POWER PACK MMPP4302-R MMPP4302-PKG-R SERVICE MANUAL MMPP4303-PKG-R MMPP4303-PKG-3-R MMPP4305-PKG-R MMPP4305-PKG-3-R MMPP4307-PKG-R MMPP4307-PKG-3-R MMPP4307-PKG-4-R v1.0...
- Page 2 2 | REMOTE POWER PACK SERVICE MANUAL MICROMATIC.COM | 866-327-4159...
-
Page 3: Table Of Contents
TABLE OF CONTENTS EQUIPMENT SPECIFICATIONS ................4-5 INSTALLATION ......................6-8 MAINTENANCE ......................8 CHANGING GLYCOL PUMP ..................9 REPLACING MOTOR ....................10 REPLACING THERMOSTAT ..................10 TROUBLESHOOTING ....................11 SPARE PARTS ......................12 WIRING DIAGRAMS ....................13 WARRANTY INFORMATION ..................15 MICROMATIC.COM | 866-327-4159 REMOTE POWER PACK SERVICE MANUAL | 3... -
Page 4: Equipment Specifications
EQUIPMENT SPECIFICATIONS MODEL MMPP4302-R MMPP4302-PKG-R MMPP4303-PKG-R MMPP4303-PKG-3-R MMPP4305-PKG-R Type Air Cooled Air Cooled Air Cooled Air Cooled Air Cooled BTUs* 3,600 3,600 5,100 5,100 7,250 Compressor HP Glycol Pumps Rotary Vane Rotary Vane Rotary Vane Rotary Vane Rotary Vane Pump Type... -
Page 5: Equipment Specifications
EQUIPMENT SPECIFICATIONS MODEL MMPP4305-PKG-3-R MMPP4307-PKG-R MMPP4307-PKG-R MMPP4307-PKG-4-R Type Air Cooled Air Cooled Air Cooled Air Cooled BTUs* 7,250 11,500 11,500 11,500 Compressor HP 1 1/2 1 1/2 1 1/2 Glycol Pumps Rotary Vane Rotary Vane Rotary Vane Rotary Vane Pump Type Pump GPH Pump Motor HP Pump Inlet/Outlet Barbs... -
Page 6: Installation
NOTE: In units with more than one pump, connect a glycol line to each pump outlet. 4. Connect the second glycol line from each circuit to the glycol bath inlet. 5. Fill the glycol bath with Micro Matic Polar Flo glycol solution: ®... -
Page 7: Installation
CONDENSING UNIT INSTALLATION STEPS NOTICE - INSTALLATION AND SERVICE OF THE REFRIGERATION AND ELECTRICAL COMPONENTS MUST BE PERFORMED BY A REFRIGERATION MECHANIC OR LICENSED ELECTRICIAN. DANGER – EQUIPMENT MUST BE PROPERLY GROUNDED. IMPROPER OR FAULTY HOOK-UP OF ELECTRICAL COMPONENTS OF THE REFRIGERATION UNITS CAN RESULT IN SEVERE INJURY OR DEATH. -
Page 8: Maintenance
If unit is operating properly, replace the cover on condensing unit. MAINTENANCE 1. Inspect the unit monthly to ensure that the glycol level is maintained to the full level. 2. If the level is low replace with a Micro Matic Polar Flo glycol solution: ®... -
Page 9: Changing Glycol Pump
ELECTRONIC TEMPERATURE CONTROL WITH DISPLAY NOTE: When the unit leaves the factory the electronic thermostat is pre-set to the following parameters: Temperature Scale: F (Fahrenheit) Setpoint: 29° F Differential: 3° F SERIES MMP4305 AND MMPP4307 Temperature Scale: F (Fahrenheit) Setpoint: 28°... -
Page 10: Replacing Motor
REPLACING MOTOR 1. Unplug unit from receptacle. 2. Support pump and loosen clamp holding pump to motor. As clamp is loosed pump will eventually disconnect from motor. Make sure pump does not damage glycol supply line as it becomes free from motor. 3. -
Page 11: Troubleshooting
TROUBLESHOOTING TROUBLE CAUSE SOLUTION Excessive foam A. Adjust cooler temperature to 36° to 38°F Warm walk-in cooler (use a quality thermometer) B. Check applied pressure to keg Adjust setting on regulator for proper flow rate of two (2) ounces per second. C. Check equipment Check the physical equipment from keg to faucet D. Warm product lines Refer to #5 Compressor relay or capacitor Replace compressor relay or capacitor... -
Page 12: Spare Parts
TYPICAL SPARE PARTS Component Part Number 125' 250' 350' 500' COMPONENT PART NUMBER MMPP4301-EP MMPP4301 MMPP4302 MMPP4303 MMPP4305 MMPP4307 Vane Pump and Motor Assembly MMPP4301-PPM Pump Insulation MM-IPCPRO Vane Pump Assy PP4301-PPA Motor (1/3 HP) MMPP4301-M Motor (1/3 HP 220 Volt) MMPP4305-M Vane Pump Key MM-3362-2... -
Page 13: Wiring Diagrams
WIRING DIAGRAMS MICROMATIC.COM | 866-327-4159 REMOTE POWER PACK SERVICE MANUAL | 13... - Page 14 NOTES 14 | REMOTE POWER PACK SERVICE MANUAL MICROMATIC.COM | 866-327-4159...
-
Page 15: Warranty Information
Matic shall, at its option, repair (or authorize the repair of), or replace or refund the purchase price for the Products found by Micro Matic to be defective. Micro Matic’s determination of defects is final. Failure by Purchaser to give notice of claims of breach of warranty within the Warranty Period shall be deemed an absolute and unconditional waiver of Purchaser’s claim... - Page 16 02035-R-MM-M-0519 ©2019 Micro Matic USA, Inc. All Rights Reserved. Micro Matic reserves the right to change specifications without notice.
