I N S TA L L AT I O N A N D S E T U P G U I D E
i D E V I C E S S M A R T H O M E S O L U T I O N S
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the INSTANT SWITCH and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for iDevices INSTANT SWITCH

Summary of Contents for iDevices INSTANT SWITCH

  • Page 1 I N S TA L L AT I O N A N D S E T U P G U I D E i D E V I C E S S M A R T H O M E S O L U T I O N S...

  • Page 2: Bluetooth Technology

    R E Q U I R E S T O O L S N E E D E D • A Compatible iDevices Product When installing into a gang box, you ® • iDevices Connected app will need the following tools: ®...
  • Page 3 • The iDevices Instant Switch must be installed in a manner that conforms to all applicable national, ® state, and local building codes. • When installing with Command Strips from 3M, do not install above a bed, onto wallpaper, or outdoors.

  • Page 4: Before You Start

    Bluetooth signal ® strength. • Check that your mobile device is compatible with the iDevices ® Instant Switch at iDevicesinc.com/Compatibility • It is YOUR responsibility to be sure that products are installed in accordance with applicable building codes.
  • Page 5 • The iDevices Instant Switch requires an existing iDevices product ® to function. Find additional products at iDevicesinc.com/Store • Download the free iDevices Connected app. ®...
  • Page 6 I N S TA N T S W I T C H ® Turn Light On/Increase Brightness. (Note: Dimmable feature only available when paired to a dimmable iDevices product). Single tap to ® turn light on. Press and hold to increase brightness level. Double tap to quickly increase light to maximum brightness.
  • Page 7 3M Command™ Strip Access Door. Remove to access 3M Command™ Strip when removing Instant Switch from wall. Level. Built-in level ensures exact installation. Switch Unit Removal. Press sides to remove Switch from mounting plate to access battery. Pairing Reset. Press and hold for 10 seconds, until LED blinks red.
  • Page 8 D E V I C E S I N S TA N T S W I T C H ( C O N T. ) ® Ground Wire Assembly. Connect to Instant Switch when installing into a gang box.

  • Page 10: Using For The First Time

    USING FOR THE FIRST TIME REMOVE BATTERY PULL TAB Before using the iDevices Instant Switch for the first time, you will ® need to remove the battery tab. Pull the plastic tab out of the back of the product and discard.

  • Page 12: Installation Methods

    I N S TA L L AT I O N M E T H O D S There are 3 methods in which you may install your Instant Switch: By itself on the wall, using the provided 3M Command™ Strip...
  • Page 14 • Remove the plastic backing to the Command™ Strip & align the strip with the recessed area on the back of the Instant Switch. • Peel off the other side of the plastic backing and ensure that the product is level before pressing firmly to the wall for 30 seconds.
  • Page 16 • Mount to the wall using the 3M Command™ Strip next to an existing gang box, as directed on page 14. • Install a multiple rocker switch faceplate (not included) directly over the Instant Switch and the existing switches to create a multi- switch grouping.
  • Page 18 INSTALL INTO GANG BOX • Turn OFF the power to the circuit you are working on at your home’s breaker or fuse panel. • Install the Ground Wire Assembly onto the access door of the Instant Switch.
  • Page 20 INSTALL INTO GANG BOX (CONT.) • Connect the ground wire on the Instant Switch to the ground wire in the gang box, which is usually bare cooper or green.
  • Page 21 GROUND (Usually Bare Copper or Green)
  • Page 22 • Turn the power back on at your circuit breaker. CAUTION: It is not intended to use the iDevices faceplate when mounting the iDevices ® ® Instant Switch in a gang box. Instead, use a standard rocker faceplate of your choice (not included).

  • Page 24: Replacing Battery

    B AT T E RY REPLACING BATTERY • The iDevices Instant Switch uses a standard CR2032 battery, and ® lasts up to 2 years. • Access the battery by pressing the module assembly in where noted and tilting the top toward you to remove from the mounting plate.
  • Page 26 REPLACING THE MODULE ASSEMBLY • Line up the tabs on the bottom of the module assembly with the arrows on the bottom of the mounting plate. • Tip the top of the module assembly up and press it firmly until it clicks into place.
  • Page 28 R E M O V I N G Y O U R WA L L M O U N T E D I N S TA N T S W I T C H • Remove the Access Door to expose the end of the 3M Command Strip.

  • Page 30: Reference Information

    R E F E R E N C E I N F O R M AT I O N LED COLOR CODES LED State Instant Description Instant Switch is in pairing mode. The LED flashes blue. Blue Flash Pairing mode has been completed. The LED will turn solid blue.
  • Page 31 On button press, if battery needs replacement, the LED will rapidly flash red 5 times. Red Flash On button press, if Instant Switch has lost the link with it’s paired iDevices product, the LED will turn solid red for 5 seconds. Solid Red When Instant Switch is performing a software update, it flashes purple.
  • Page 32 S U P P O RT If at any time you require assistance, please contact our Customer Experience Team. 888.313.7019 Support@iDevicesinc.com iDevicesinc.com/Support...

  • Page 33: Troubleshooting And Support

    T R O U B L E S H O O T I N G A N D S U P P O RT A DEVICE RESET CAN RESOLVE MOST ISSUES. Device Reset. Press and hold 7+1 simultaneously for 10 seconds, then release to cycle power to the device.

  • Page 34: Regulatory Information

    R E G U L AT O RY I N F O R M AT I O N Product Information: Manufacturer: iDevices ® Model: IDEV0020 FCC: 2ABDJ-IDEV0020 IC: 11569A-IDEV0020 The iDevices Instant Switch IDEV0020 is certified to comply with applicable ® FCC and IC rules and regulations governing RF and EMI emissions.

  • Page 35: Fcc Notice

    FCC Notice This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation.
  • Page 36 • Reorient or relocate the receiving antenna. • Increase the separation between the equipment and receiver. • Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. • Consult the dealer or an experienced radio/TV technician to help. • Changes or modifications not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment.
  • Page 37 brouillage radioélectrique subi, même si le brouillage est susceptible d’en compromettre le fonctionnement. This device complies with the Industry Canada license exempt RSS standard(s). Operation is subject to the following two conditions: (1) this device may not cause interference, and (2) this device must accept any interference, including interference that may cause undesired operation of the device.
  • Page 38 Apple Inc. Android is a trademark of Google Inc. Google Play and the Google Play logo are trademarks of Google Inc. The Bluetooth® word mark and logos are registered trademarks owned by the Bluetooth SIG, Inc. and any use of such marks by iDevices is under license. Other trademarks and ®...
  • Page 40 iDevicesinc.com...
