- Page 1 P73099-F8E203-US-man-qxd 3/9/00 8:15 AM Page 1 ErgoMouse ™ User Manual F8E203 P73099 F8E203-BLK...
-
Page 2: About Your Mouse
P73099-F8E203-US-man-qxd 3/9/00 1. Introduction ABOUT YOUR MOUSE 1.1 An Introduction to Your New Belkin ErgoMouse The Belkin ErgoMouse ™ offers the ultimate in value and comfort. A gentle thumb cradle supports your thumb, allowing the rest of your fingers to rest naturally on the buttons, giving you true ergo support. - Page 3 1. Introduction 1.2 Connecting Your Mouse Your mouse connects to either a PS/2 (or 6 pin MiniDIN) mouse port or a 9 pin serial port. To verify your connectors, locate the port on the back of your computer that is designated for your mouse.
-
Page 4: Software Installation
Type "A:INSTALL" (or "B:INSTALL") and then click on "OK". e. Click "Next". Click "Next". g. Specify if you are using a PS/2 or Serial mouse (see Section 1.2). h. Click “Next”. Click “Yes, I want to restart my computer”, then click “Finish”. -
Page 5: Troubleshooting
If you have more than one driver, this could be causing your computer to boot in safe mode or not allow your mouse to work at all. If you are using a PS/2 mouse then the driver must state that it is using a PS/2 driver. If you are using a Serial mouse then the driver must state that it is using a Serial driver on COM1 or COM2. - Page 6 "Computer" and then use the "Down Arrow" until your "Mouse" is highlighted. Then use your "Right Arrow" to expand and select your mouse driver or drivers. After you have chosen your mouse driver you can now modify it by removing the driver or changing the driver.
- Page 7 "Computer" and then use the "Down" Arrow until your "Mouse" is highlighted. Then use your "Right" Arrow to expand and select your mouse driver or drivers. After you select the mouse driver, use your "Tab" key to select "Properties" and then press "Enter". Use your "Right Arrow"...
- Page 8 Why does my external mouse not work with my laptop computer? You may have to disable the onboard mouse in order to use an external mouse. Try looking in your CMOS or BIOS in order to disable the onboard mouse. If you do not have this...
- Page 9 P73099-F8E203-US-man-qxd 3/9/00 8:15 AM Page 8 4. How to Use Your ErgoMouse ™ 4.1 Changing Mouse Settings You will find the CursorWare ™ program in your taskbar on the bottom of your screen. Click on it to open the window.
- Page 10 You can choose between solid white, solid black or clear. To the left, you will find the section marked "Mouse Speed". Mouse Speed determines how quickly your pointer moves about the screen. The faster the setting, the higher the response.
- Page 11 However, if the pointer should skip or move abnormally on screen, we recommend you clean your mouse manually. a. First, turn the retainer ring counterclockwise to remove the ball.
- Page 12 Double click on the “Windows “Main Group”. Select “Options”. Select “Change System Setting …” in Windows Select “Mouse:\”. Choose the new mouse driver you require. This will override any previous settings. If you are prompted to keep current driver, click on “Current”. 5.2 Windows ®...
-
Page 13: Fcc Statement
Belkin Components warrants this product against defects in materials and workmanship for its lifetime. If a defect is discovered, Belkin will, at its option, repair or replace the product at no charge provided it is returned during the warranty period, with transportation charges prepaid, to the authorized Belkin dealer from whom you purchased the product. - Page 14 Belkin Components B.V. Diamantlaan 8 • 2132 WV Hoofddorp • The Netherlands Tel: +31 (0) 235698765 Fax: +31 (0) 235612694 © 2000 Belkin Components. All rights reserved. All trade names are registered trademarks of respective manufacturers listed. 8:15 AM Page 13...
