EMOTIV EPOC QUICK START GUIDE

Access software from your Emotiv user account MY EMOTIV > MY DOWNLOADS. You will be prompted to enter a serial

key and order number found when clicking the key button.

MAKE SURE ALL ITEMS ARE PRESENT IN YOUR KIT

BEFORE STARTING

INITIAL CHARGING OF THE HEADSET

The headset must be set to the "oﬀ" position before

charging.

Recharge to 100% capacity in approximately 4 hours.

Charging for 30 minutes yields about a 10% increase

in charge. LED will light to green when fully charged

and red when drained. The neuroheadset should not

be charged when on the head.

Always hydrate the sensors in the provided Hydrator Pack.  

The inserts must be fully saturated with saline solution for

good contact to be achieved.

Add drops of saline to saturate the large white hydrator pad

attached to the top cover of the hydrator pack, then close the

cover and gently shake. This will maintain the moisture of the

felt pads when they are not in use.

Note: Replenish with standard multipurpose contact lens

saline solution.

Table of Contents

Do you have a question about the EPOC and is the answer not in the manual?

Page 1 The neuroheadset should not be charged when on the head. SOFTWARE INSTALLATION Access software from your Emotiv user account MY EMOTIV > MY DOWNLOADS. You will be prompted to enter a serial key and order number found when clicking the key button.  ...
Page 2 SENSOR ASSEMBLY Remove the sensor units with their felt pads from the hydrator pack and insert each one into the black plastic headset arms, turning each one clockwise one-quarter turn until you feel a "click". The sensor units should be stored in the hydrator pack when not in use.
