- Page 1 M I N T R O N I X C O M P U T E R S O L U T I O N S M P 5 0 0 0 C 1 2 ” A L L - I N - O N E T O U C H S C R E E N C O M P U T E R S Y S T E M User’s Guide...
- Page 2 Furthermore, the original manufacturer assumes no liability arising from use of the products described herein. Working with the MP5000C computer involves hazardous levels of voltages and can present serious shock hazard.
-
Page 3: Table Of Contents
M I N T R O N I X C O M P U T E R S O L U T I O N S Table of Contents Introduction Standard Features Input/Output Graphics Touch Screen Power Supply Environment Physical Dimensions Optional Accessories 10.0 Setup Installation... -
Page 4: Version
M I N T R O N I X C O M P U T E R S O L U T I O N S 23.3 TOLUD Value 24.0 Chipset Configuration-South Bridge 15-16 24.1 Azalia HD Audio 24.2 USB Configuration 24.3 PCI Express Configuration 25.0... -
Page 5: Introduction
M I N T R O N I X C O M P U T E R S O L U T I O N S 1.0 Introduction The All-in-One touch screen computer with adjustable viewing angle has the flexibility of a PC-based computer and architecture combined with advanced LCD and touch screen technology to form a low cost, small-sized computer that runs all PC-based software. -
Page 6: Input/Output
M I N T R O N I X C O M P U T E R S O L U T I O N S 3.0 Input/Output Serial RS-232/422/485 for COM1, 3 RS-232 for COM2/3/4 Ethernet Controller: Realtek RTL8111E-VL-CG •... -
Page 7: Touch Screen
M I N T R O N I X C O M P U T E R S O L U T I O N S 5.0 Touch Screen Touch Screen 5 wire resistive technology integrated USB controller, using mouse emulation 6.0 Power Supply Power Supply Single +12V DC ±... -
Page 8: Setup Installation
Insert stand front tabs into slots on back of MP5000C Remove the screw on the center top of the MP5000C and use it to secure the stand to the computer 124 Old Mill Road, Suite H... -
Page 9: Bios Introduction
The Setup program uses several menus for making changes. 11.1 BIOS Setup The MP5000C computer has the AMI BIOS built in, with a CMOS SETUP utility that allows users to configure required settings or to activate certain system features. -
Page 10: Bios Main Menu
M I N T R O N I X C O M P U T E R S O L U T I O N S 11.2 BIOS Main Menu Press <Del> to enter AMI BIOS CMOS Setup Utility, the Main Menu will appear on the screen. -
Page 11: Bios Operation
M I N T R O N I X C O M P U T E R S O L U T I O N S 11.3 BIOS Operation The Main BIOS setup screen has two main frames. The left frame displays all the options that can be configured. -
Page 12: Super I/O Configuration
M I N T R O N I X C O M P U T E R S O L U T I O N S 13.0 Super I/O Configuration Serial Port 1 Configuration - Set Parameters of Serial Port 1 (COM1). ... -
Page 13: Ppm Configuration
M I N T R O N I X C O M P U T E R S O L U T I O N S Intel Virtualization Technology. When enabled, a VMM can utilize the additional hardware capabilities provided by Vanderpool Technology. [ Enabled ] ... -
Page 14: Usb Configuration
M I N T R O N I X C O M P U T E R S O L U T I O N S 21.0 USB Configuration Legacy USB Support - Enables Legacy USB support. AUTO option disables legacy support if no USB devices are connected. -
Page 15: Intel Igd Settings
M I N T R O N I X C O M P U T E R S O L U T I O N S 23.1 Intel IGD Settings DVMT Pre-Allocated - Select DVMT 5.0 Pre-Allocated (Fixed) Graphics Memory size used by the Internal Graphics Device. -
Page 16: Azalia Hd Audio
Configure PCIe Port Speed. [ Enabled ] 25.0 Security Select Security Setup from the MP5000C Setup main BIOS setup menu. All Security Setup options, such as password protection and virus protection are described in this section. To access the sub menu for the following items, select the item and press <Enter>:... -
Page 17: Boot
M I N T R O N I X C O M P U T E R S O L U T I O N S 26.0 Boot Setup Prompt Timeout - Number of seconds that the firmware will wait before initiating the original default boot selection. -
Page 18: Jumper Settings
29.2 Touch Screen Driver The MP5000C has an ELO serial touch controller. A universal driver is included in the respective ELO touch directory. 29.3 Tuning the Touch Screen Under Windows If you wish to calibrate the touch screen while under Windows, go to “Control Panel”... -
Page 19: Troubleshooting
M I N T R O N I X C O M P U T E R S O L U T I O N S 30.0 Troubleshooting If your system does not operate correctly at first, re-read the instructions regarding the procedure being performed. -
Page 20: Connection Problems
M I N T R O N I X C O M P U T E R S O L U T I O N S 30.3 Connection Problems If you are having problems with your peripherals and have checked the possible solutions above, the connection between your Panel Touch and the peripheral may be the problem. -
Page 21: Reader Test
They are factory preset and normally do not need to be changed by the user. To enter the setting mode: Connect keyboard to your MP5000C computer. Run .MSR213U setting AP Follow instructions on the screen to change settings 32.3 Power-Up Initialization...
