Belkin F5U302 Quick Install Manual

Make sure you have the
following package contents:
Wireless Wireless USB Adapter Stand Power
USB Hub Adapter Supply
(optional)
Mini-USB Cable Installation Quick
Installation
(A to Mini-B) CD
Guide

Package Contents

Setup for XP Users

1. Insert the Belkin driver-installation CD into your CD-ROM drive.
After a few moments, the setup application should appear on
your computer screen.
Note: If the setup application does not appear, double-click "My
Computer", and then click your CD-drive icon. This will load the
setup-applications main page.
2. Click "Install driver" and follow the prompts to complete the
software-install process.
3. a. Connect the power supply to the Hub.
b. Attach the mini-USB cable to the mini-USB port on the side of the Hub
and the other end to your computer's built-in USB port (Fig. 1). This will
allow your computer to recognize the Hub.
Fig. 1
(A) (B)
Connect the Connect
power supply mini-USB cable
4. Wait approximately one minute for security to become enabled. A
prompt will indicate that the security setup is complete (Fig. 2).
Fig. 2
1 Setup for XP Users
5. Once this process is complete, unplug and remove the mini-USB cable from the
Hub and computer. This cable is needed only on the first installation. Store the USB
cable for another computer installation if desired.
6. Connect the Wireless USB Adapter to your computer's USB port.
Windows will automatically find and load drivers to complete installation (Fig. 3).
Fig. 3
7. Plug your USB devices into the Hub and access them wirelessly (Fig. 4).
Fig. 4
2 Setup for XP Users 3
