- Page 1 HEAT PUMP WATER HEATER Installation & Instruction Manual...
-
Page 2: Table Of Contents
1.Introduction for product 2.Operation principles 3.Performance data 4.Installation 4.1. Dimensions 4.2. Free space for installation 4.3. About water tank 4.4. Pipeline connections 4.5. Pre-operation 4.6. Normal operation 5.Operation 5.1. Controller illustration 5.2. Selecting mode 5.3. Checking current parameters 5.4. Parameter overview (Table 1) 5.5. -
Page 4: Introduction For Product
1.PRODUCTION INTRODUCTION... -
Page 5: Operation Principles
2.OPERATION PRINCIPLES The compressor absorbs from the evaporator the low-temperature and low-pressure gas refrigerant, compress the refrigerant into high-temperature and high-pressure gas, and the gas will enter the condenser to exchange energy with water, during which, the gas is condensed in the condenser into low-temperature liquid to discharge a lot of heat, which is absorbed by water to increase its temperature. -
Page 6: Performance Data
3.PERFORMANCE DATA ITS-4.7HDP Code ITS-17VD ITS-24.5VD3 4700 17000 24500 Rated Heating Capacity 16000 58000 83600 BTU/h 380/3/50 Power Supply 220/1/50 V/PH/Hz Input Power 1170 3600 5000 Running Current 17.2 Hot Water Produced Volume Thermostat Factory Setting ℃ ℃ Maximum water temp... -
Page 7: Installation
2.Installation 4.INSTALLATION ITS-4.7HDP ITS-17VD ITS-24.5VD3 Code Specs 2.5mm 13AWG 4.0mm /11AWG 4.0mm /11AWG 4.1. Dimensions B SERIES Unit：mm Model Size ITS-4.7HDP... - Page 8 A SERIES Unit：mm Model Size ITS-17VD ITS-24.5VD3...
-
Page 9: Free Space For Installation
4.2. Free space for installation ◎ It should be installed in places with large space and good ventilation. ◎ The installation position should guarantee smooth air exhale (for air inhale, refer to the follow -ing figure). ◎ Position close to drainage channel or vent to facilitate water discharge is strongly recommended. ◎... -
Page 10: Pipeline Connections
4.4. Pipeline connection ◎ The water leak pipe or water overflow pipe should be installed near the drainage channel or vent to facilitate water discharge. Water leak valve should be installed in the water leak pipe. ◎ Before the electromotive electromagnetic valve in system pipeline, a check valve should be installed for future check. -
Page 11: Operation
5. OPERATION 5.1. Controller illustration: Standby Running status status Actual tank water temp. When heat pump is supplied with power, controller will display full screen, shows that it’s already connected. If connection fails in 10 seconds, please check connections of communication cable or replace anther controller. -
Page 12: Selecting Mode
5.2. Selecting mode ◎ Press ＂M＂to select heating mode. Remarks: Except heating mode is available, other modes are in valid. 5.3. Checking current parameter ◎ Under standby status or running status press ＂ ＂or＂ ＂ controller will display from Parameter 0 to Parameter 13 in turn with current value. -
Page 13: Parameter Overview (Table 1)
5.4. Parameter table overview (Table 1) Αpplicable models: ITS-4.7HDP Description Range Parameter Default Note Adjusted by technician Reserved 1-30℃ 15℃ Setting desired water temp.in water tank Adjustable 10-60℃ 40℃ Defrosting cycle Adjusted by technician 30-90Min 45Min Temp. point of entering defrosting Adjusted by technician 0--30℃... -
Page 14: Parameter Overview (Table 2)
5.5 Parameter table overview (Table 2) Αpplicable models: ITS-17VD ITS-24.5VD3 Meaning Scope Parameter Default Note Setting of inlet temp. to start electric auxiliary HT1(optional) Adjusted by technician 1-30℃ 15℃ Setting desired water temp.in water tank Adjustable 10-60℃ 40℃ Defrosting cycle Adjusted by technician 30-90Min 45Min... -
Page 15: Setting Parameter
5.6. Setting Parameters ◎ Press ＂ ＂controller displays from Parameter 0 to Parameter 13 in turn with current actual value. ◎ Press SET to activate, controller displays flashing value. ◎ Press ＂ ＂ or ＂ ＂to change value. ◎ Press SET again to confirm. ◎... -
Page 16: Failure Code Overview
6. FAILURE CODE OVERVIEW Applicable models: ITS-4.7HDP Wire PCB LED indicator Possible cause Check & solution Protection Failure controller Standby status Running status Inlet water temp. ☆● sensor failure (1 flashes & 1 pause) ☆☆● Discharge gas temp. (2 flashes & 1 pause) sensor failure ☆☆☆●... - Page 17 Applicable models: ITS-17VD ITS-24.5VD3 Wire PCB LED indicator Possible cause Check & solution Protection Failure controller Standby status Running status Inlet water temp. ☆● sensor failure (1 flashes & 1 pause) ☆☆● Outlet water temp. (2 flashes & 1 pause) sensor failure ☆☆☆●...
-
Page 18: Wiring Diagram
7.WIRING DIAGRAM ITS-4.7HDP 4-Way Valve PUMP BLU RED Y/G WHI BLK BLU Y/G BLU RED 4-Way High Electric Middle Electric heater of heater valve external tank Return gas temp Ambient temp OUT1 OUT2 Coil temp Exhaust temp Tank sensor connector... - Page 19 ITS-24.5VD3 4- Wa y va lv e U V W El ec tr on ic Electri c heater of external tank ex pa nd in g va lv e RE D BL K WH I D0 1 Ta nk se ns or co nn ec to r Wa te r pu mp L1 1 L2 1 L3 1...
-
Page 20: Maintenance
8. MAINTENANCE The heat pump water heater is highly automatic equipment, which is checked periodically over its unit state in application. If the unit can be maintained effectively for a long time, the operation reliability and lifespan of the unit will be greatly enhanced. 1 The water filter installed outside the unit should be cleaned periodically to ensure a clean water supply in the system in case the unit may be damaged due to the blocked dirty water filter.
