Exposure Device Specifications
Manufacturer
Sentinel - QSA Global, Inc.
40 North Avenue, Burlington, Massachusetts, USA 01803
Primary Application
Industrial gamma radiography
Model Numbers
Model 880 Delta, Model 880 Sigma, Model 880 Elite
and Model 880 Omega
Weight of Exposure Device
Delta: 52 lb (24 kg), Sigma: 52 lb (24 kg)
Elite: 42 lb (19 kg), Omega: 33 lb (15 kg)
Weight of Depleted Uranium Shield
Delta: 34 lb (15.4 kg), Sigma: 34 lb (15.4 kg)
Elite: 25 lb (11.4 kg), Omega: 17 lb (7.7 kg)
Activity of Depleted Uranium Shield
Delta: 5.4 mCi (200 MBq), Sigma: 5.4 mCi (200 MBq)
Elite: 3.8 mCi (141 MBq), Omega: 2.7 mCi (101 MBq)
Special Form Certifications
Iridium-192, Cobalt-60 & Cesium-137:
Selenium-75:
Ytterbium-169:
Length
13.33 in (33.8 cm) all models
Width
7.5 in (19.1 cm) all models
Height
9 in (22.9 cm) all models
Type B(U) Certification
The Models 880 Delta, 880 Sigma and
880 Elite are certified by the following:
Type A Approval
All Models meet the Type A package
requirements of 49 CFR 173.415 and
IAEA TS-R-1 (1996 revised)
USA/0335/S-96
USA/0502/S-96
USA/0597/S-96
1.5
TECHNICAL SPECIFICATIONS
USA/9296/B(U)-96
CDN/E199/-96
