Note:
The total length of source guide tubes utilized must be shorter in length than the remote controls to
ensure the source assembly will project into the working position.
e.g. When using 25 ft (7.6 m) remote controls, a maximum of three 7 ft (2.1 m) source guide tubes can be
used with a combined length of 21 ft (6.4 m).
Conversely, when using 35 ft (10.7 m) remote controls, a maximum of four 7 ft (2.1 m) source guide tubes
can be utilized.
When using 50 ft (15 m) remote controls, a maximum of six 7 ft (2.1 m) source guide tubes can be
utilized. This limitation is due to the weight and friction of remote control cable length.
Control Specifications
Complete Remote Control Assemblies
Product code Model number Control cable length
TAN66425 664/25
TAN66435 664/35
TAN66450 664/50
TAN69325 693/25
TAN69335 693/35
TAN69350 693/50
TAN69225 692/25
TAN69235 692/35
TAN69250 692/50
88325 883/25
88335 883/35
88350 883/50
Model 664 Control Storage Reel Unit Size
Length Width
21 in (533 mm) 12 in (305 mm)
The Model 664 reel and 693 pistol grip controls are equipped with odometers. The Model 692 pistol-grip
controls are not equipped with an odometer.
Source Guide Tube (with source stop)
Product Code Model Number
TAN48906 48906
48906-X 48906-X
48931-7 48931-7
48931-X 48931-X
95020 95020
95020-X 95020-X
Source Guide Tube Extension
Product Code Model Number
TAN48907 48907
48930-7 48930-7
48930-X 48930-X
95021 95020
95021-X 95021-X
NOTE:
X indicates customer can order lengths other than the standard length.
Unit weight
25 ft (7.6 m) 21 lb (10 kg)
35 ft (10.7 m) 24 lb (11 kg)
50 ft (15.2 m) 27 lb (12 kg)
25 ft (7.6 m) 21 lb (10 kg)
35 ft (10.7 m) 24 lb (11 kg)
50 ft (15.2 m) 27 lb (27 kg)
25 ft (7.6 m) 21 lb (10 kg)
35 ft (10.7 m) 24 lb (11 kg)
50 ft (15.2 m) 27 lb (12 kg)
25 ft (7.6 m)
35 ft (10.7 m)
50 ft (15.2 m)
Height
6.6 in (168 mm)
Length
7 ft (2.1 m) male 1-18 threaded fitting
Customer specified length
7 ft (2.1 m) with bayonet fitting
Customer specified length with bayonet fitting
7 ft (2.1m) male 1-18 threaded fitting
Customer specified length
Length
7 ft (2.1 m) male/female 1-18 threaded fittings
7 ft (2.1 m) bayonet fitting/female 1-18
Customer specified length bayonet fitting/female 1-18
7 ft (2.1 m) male/female 1-18 threaded fittings
Customer specified length
1.4
TECHNICAL SPECIFICATIONS
