C70EN07Z1
E ENGLISH
USER'S MANUAL
This manual explains how to use the SIGMA DP1 digital camera.
Please refer to the SIGMA Photo Pro User Guide, which is available in the
PDF format of the supplied CD-ROM, to get information about installation of
SIGMA Photo Pro software to your computer, connection between camera
and computer and for detailed explanation of SIGMA Photo Pro software.
111
