GSD i70 Installation Manual
Grade 2 intrusion rf repeater
Hide thumbs
Also See for i70:
- Installation manual (20 pages) ,
- User manual (8 pages) ,
- Installation manual (2 pages)
Advertisement
Technical specification
GSDi-RF-RPT
Name of manufacturer
Global Security Devices Ltd
Description of equipment
RF Repeater
Standards
EN50131-1:2006
EN50131-2-2:2009
EN50131-6:2008
PD6662:2010
EN60950:2006
Security grade
Grade 2
Environmental class
Class II
Operating temperature
-10ºC to 40ºC
Relative humidity
Up to 75% non-condensing
Functions
Enclosure tamper detection
Removal from mounting tamper detection
Battery voltage monitor
Inputs
None
Signals / Indications
Condition
Tamper
Low battery
Total supply loss
Dimensions (w d h)
68mm 48mm 130mm
Power supply description
8V to 14V
Battery
1 x ICR123 LI-ion 750 mA rechargeable battery.
Nominal voltage 3.7V. Low voltage indication
below 2.6V. Life typically > 30 hours backup
Global Security Devices Ltd: No.3 Broomhill Business Complex, Tallaght,
Dublin 24, Ireland, Phone: +353 (1) 524 2691, Email: info@globalsecurity.ie
www.globalsecurity.ie
Signal
Tamper
Low battery fault
Loss of communication
Contents
Technical Specification
Grade 2 Intrusion RF Repeater
Installation Manual
YOUR SECURITY IS OUR PRIORITY
2
3
4
i 70
V1.00
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for GSD i70
Summary of Contents for GSD i70
- Page 1 YOUR SECURITY IS OUR PRIORITY Technical specification GSDi-RF-RPT Name of manufacturer Global Security Devices Ltd Description of equipment RF Repeater Standards EN50131-1:2006 EN50131-2-2:2009 EN50131-6:2008 PD6662:2010 EN60950:2006 Security grade Grade 2 Environmental class Class II Contents Operating temperature -10ºC to 40ºC Relative humidity Up to 75% non-condensing Operation Instructions...
- Page 2 Rechargeable Remove battery Tab 750mA Battery Connect power (5 - 13V) to the Terminals, ie.:i70 Panel Aux Power Press and hold the front tamper. If removing PCB from the base, ensure that the back tamper is closed before closing front tamper.
