Summary of Contents for Linak JUMBO Care
- Page 1 Service readout and Service Data Tool 2 with JUMBO Care User manual LINAK.COM/MEDLINE-CARELINE Page 1 of 12...
-
Page 2: Table Of Contents
When does the service time starts counting? ................. 4 How to change to another service interval? ................... 4 Read out service data on a JUMBO Care with display ............... 5 Read out service data on a laptop ....................6 Equipment needed to read out service data ................... 6 How to connect the equipment and get started ................ -
Page 3: Preface
IB300001 user manual where this procedure is explained. If you experience any problems with your new JUMBO Care you are always welcome to contact your local LINAK representative who will be able to help you. -
Page 4: Service Intervals
You can also choose ‘NO months’ or ‘NO cycles´. E.g. Push M = 24, Push 10000. The JUMBO Care is now set to indicate service need every 24 month or at 10000 cycles whichever comes first. -
Page 5: Read Out Service Data On A Jumbo Care With Display
Read out service data on a JUMBO Care with display When you have a JUMBO Care with display it is possible to have some basic service data on the display. To get this information on the display press the “lifting arm up” button on your LINAK hand control (short press ½... -
Page 6: Read Out Service Data On A Laptop
When reading out service information on a laptop you need: • Service data tool 2 version 1.3.4 or newer version installed on the laptop. The software will be provided from your local LINAK sales representative. • An OpenBus programming and data read out box (item number IB300001) •... -
Page 7: What To Read Out On The Laptop
What to read out on a laptop Ensure the JUMBO Care view is initiated by pressing the menu shown. Go to the Diagnosis menu page 1 When pressing a hand control button: Input signals will give a receipt in the service data tool. -
Page 8: How To Conclude On The Service Information
When an actuator needs to be exchanged this has to be registered in the Service Data Tool. Replace actuator 1 (channel 1) or actuator 2 (channel 2) via button press to reset the JUMBO Care - then mount a new actuator. Page 8 of 12... -
Page 9: Resetting Of Service Interval After Service Has Been Carried Out
Resetting of service interval after service has been carried out. Resetting of service is done by pressing 2 Resetting of service interval buttons (lifting arm up and lifting arm down on the hand control at the same time for 5 seconds. -
Page 10: Notice
• Please note that when you disconnect the service data tool from JUMBO Care it will take 1 hour before the control box will power down. If you want to avoid the battery to consume energy the emergency stop button can be activated. - Page 11 Page 11 of 12...
-
Page 12: Addresses
While LINAK uses its best efforts to fulfil orders, LINAK cannot, for the same reasons as mentioned above, guarantee the availability of any particular product. Therefore, LINAK reserves the right to discontinue the sale of any product displayed on its website or listed in its catalogues or other written material drawn up by LINAK.
