- Page 1 ® SpiderCloud Radio Node - SCRN-220 Hardware Installation Guide ® Part number: DOC-SCRN-220-HW-01, Rev. 1 Published: April 2017...
- Page 2 SpiderCloud Wireless. Customer agrees to implement reasonable security measures to protect such trade secrets and copyrighted material at least to the extent that Customer protects its own information of a similar nature.
-
Page 3: Table Of Contents
SCRN-220 Bracket Specifications........ - Page 4 Contents SpiderCloud Wireless, Inc. Proprietary and Confidential...
-
Page 5: About This Manual
Product Overview The SCRN-220 is an integrated LTE small cell with support for Rel13 IOT devices. SpiderCloud’s scalable small cell system, called an Enterprise Radio Access Network (E-RAN), hides the complexity of radio management and mobility and provides operators with a single touch point to aggregate and manage a large network of LTE small cells. -
Page 6: Radio Node Models
SpiderCloud Radio Node - SCRN-220 Hardware Installation Guide Figure 1 on page 6 shows the logical architecture of the SCRN-220 in the network: LAN Intranet Radio Nodes PoE+ GNSS Switch Antenna Security Firewall Gateway Core IPsec IPsec Switch S1-C S1-U... -
Page 7: Radio Node System Isometric Top View And Bottom View
SpiderCloud Radio Node - SCRN-220 Hardware Installation Guide Radio Node System Isometric Top View and Bottom View The following drawings display an isometric top and bottom views of the radio node: Figure 2 Radio Node Top View Figure 3 Radio Node Bottom View SpiderCloud Wireless, Inc. -
Page 8: Antennas
SpiderCloud Radio Node - SCRN-220 Hardware Installation Guide Antennas The radio node includes four internal Tx/Rx antennas with a peak gain of 5dBi and operates in 2x2 mode with MIMO or four optional ports with QMA coaxial connectors for external antennas. Both models contain... -
Page 9: Ports
SpiderCloud Radio Node - SCRN-220 Hardware Installation Guide Ports The radio node has one 1 Gigabit Ethernet port that supports a Category 5e (Cat 5e) or better twisted-pair cable with an RJ-45 connector. Figure 6 shows the Ethernet port. There are two LEDs on the connector: •... -
Page 10: Input Power
SpiderCloud Radio Node - SCRN-220 Hardware Installation Guide Input Power The radio node receives its power from a standard Power Over Ethernet (PoE+) switch (typical) or injector. The radio node is fully compliant with the IEEE 802.3at PoE+ specification. Per IEEE 802.3at, use standard Cat 5e or better twisted-pair cable with a maximum length restriction of 100 meters (328 feet) for PoE+. -
Page 11: System Specifications
48V DC input (57V max) from a typical PoE+ injector. System Specifications The SCRN-220 radio node has the following chassis measurements, power requirements, and environmental requirements, and complies with the following standards. Refer to the feature guide for your services node software release for release-specific features and specifications. -
Page 12: Scrn-220 Bracket Specifications
1,363,791 hours at +40°C (104°F) SCRN-220 Bracket Specifications The SCRN-220 radio node connects to one of two brackets for ceiling or wall mounting: • a quarter-inch (0.64 centimeter) deep for cabling through a surface such as a wall or ceiling •... -
Page 13: Compliance
Network Listen Bands Radio Node Model SCRN-220-020412 LTE Band 2, 4, or 12 LTE 700/1900/2100MHz SCRN-220-020412-E LTE Band 2, 4, or 12 LTE 700/1900/2100MHz SCRN-220-020413 LTE Band 2, 4, or 13 LTE 700/1900/2100MHz SCRN-220-020413-E LTE Band 2, 4, or 13 LTE 700/1900/2100MHz SpiderCloud Wireless, Inc. -
Page 14: Select The Radio Node Location
Refer to the E-RAN Deployment Planning Guide for information about mounting positioning and the affects on cellular coverage. Always consult local codes about mounting and wiring SpiderCloud Wireless equipment. -
Page 15: Bracket Mounting And Cabling Guidelines
Installing the Radio Node The radio node receives its power source over powered Ethernet. If your wiring closet does not have existing PoE+ equipment, SpiderCloud Wireless recommends a PoE+ power injector for the radio node. See section Input Power on page 10. -
Page 16: Installing The Radio Node (Method 1)
SpiderCloud Radio Node - SCRN-220 Hardware Installation Guide Attach the mount bracket to the radio node as shown in Figure Bracket Keyholes Figure 11 Radio Node Slides into Mount Bracket Installing the Radio Node (Method 1) Use this method with the quarter-inch bracket when routing the Ethernet cable through an opening where the bracket will be mounted.
